Specifications and Accessories
SPECIFICATIONS
Item Number 165951
Maximum Output 7800 Watts (W)
Continuous Output 7200 Watts (W)
Voltage 120 / 240 Volt (V)
Phase Single phase (4-wire)
Frequency 60.0 Hertz (Hz)
Power Factor 100% (p.f. = 1.0)
Minimum PTO HP 14 HP at 540 RPM
Input Shaft 1-3/8” Diameter, 6 spline
120V Receptacle (2) 20 Amp (A) (NEMA 5-20R)
120/240V Receptacle (1) 30 Amp (A) locking device (NEMA
L14-30R)
Circuit Breaker (2) 20 Amp (A) thermal,
push to reset style
(1) 30 Amp (A) thermal magnetic
Gear Box
Gear Ratio 1:7
Gear Oil SAE 80W-90
Oil Capacity 0.75 Qt. (.82 L)
Dimensions
Length 25.25”
Width 12.50”
Height 17.25”
Gross Weight 110 lbs.
ACCESSORIES
PTO Driveline 165936
PTO Trailer 165959
The manufacturer reserves the right to make improvements in design and/or
changes in specifications at any time without incurring any obligation to install them
on units previously sold.
