DCA400SSI GENERATOR • OPERATION AND PARTS MANUAL — REV. #2 (11/03/08) — PAGE 79
FUEL TANK ASSY. (S/N 3813334 AND BELOW)
NO. PART NO. PART NAME QTY. REMARKS
1 C3363002503 FUEL TANK 1
1-1 0845500104 FUEL TANK CAP 1
1-2 0810105400 FUEL FILTER 1
1-3 0264100525 FUEL GAUGE HOSE 1
1-4 0605515079 HOSE BAND 2
2 0605503020 FUEL SENSOR 1
3 0802120604 PACKING 1
4 0605501089 FUEL UNIT 1
5 0605516090 PACKING 1
6 0022905015 MACHINE SCREW 5
7 8225523104 TANK BAND 2
8 0805003414 TANK BAND PAD 4
9 0016908020 HEX HEAD BOLT 2
10 0207308000 SUPER LOCK NUT 2
11 0222100300 TANK SHEET 6
12 0130206000 STREET ELBOW, 1/2” 1
13 0134306170 DRAIN PIPE 1
14 0603325026 VALVE 1
15 0132006000 PLUG, 1/2” 1
16 C1367700304 LOCK PLATE 1
17 0019208020 HEX HEAD BOLT 2
18 0845039604 RUBBER SEAL 1
19 C3366704704 BRACKET 1
20 0016910025 HEX HEAD BOLT 3
21 8980758550 PRIMARY FUEL FILTER ASSY. .................2...........REPLACES P/N 0602042405
21A 8980758540 PRIMARY FUEL FILTER ELEMENT ..........2...........REPLACES P/N 0602042516
22 8980955010 JOINT PIPE ................................................4...........REPLACES P/N 0602042662
23 1096750951 JOINT BOLT ...............................................4...........REPLACES P/N 0602042621
24 1096301110 PACKING ....................................................8...........REPLACES P/N 0602021702
25 0017110040 HEX HEAD BOLT 4
26 0010110075 HEX HEAD BOLT 2
26A 0040010000 WASHER, LOCK 2
26B 0041210000 WASHER, FLAT 2
27 0130406000 T-JOINT, 1/2” 2
28 0130206000 STREET ELBOW, 1/2” 4
29 0602022209 HOSE JOINT 6
30 0191402500 SUCTION HOSE 1
31 0191400600 SUCTION HOSE 2
32 0191400500 SUCTION HOSE 2
33 0191402800 SUCTION HOSE 1
34 0191405300 RETURN HOSE 1
35 0605515132 HOSE BAND 14
