DCA400SSI GENERATOR • OPERATION AND PARTS MANUAL — REV. #2 (11/03/08) — PAGE 57
NO. PART NO. PART NAME QTY. REMARKS
1 C3110000502 ROTOR ASSY. ..........................................1 ............. INCLUDES ITEMS W/*
1-1 FIELD ASSY 1
1-2* 0601842401 RESISTOR, 80W 300 K OHM 2
1-3* 0601823282 RECTIFIER 1
1-4* 0018205020 HEX SOCKET HEAD CAP SCREW 2
1-4A 0040005000 WASHER, LOCK 2
1-4B 0041205000 WASHER, FLAT 2
1-5* 8201070002 FAN 1
1-6* 8201611004 COUPLING DISK 12
1-7* C3164200004 COUPLING HUB WASHER 1
1-8* 8201015003 BALANCING PLATE .................................1 ............. PURCHASE ITEMS 1-11 AS A SET
1-9* 0012116045 HEX HEAD BOLT 10
1-10* 0042618000 WASHER, LOCK 10
1-11* 0601000209 BALANCING WEIGHT KIT 1
1-12 C3112500004 BEARING FLANGE 1
1-13 007906315 BEARING 1
2 C3164400103 COUPLING RING 1
3 0010312050 HEX HEAD BOLT 8
4 0042512000 WASHER, LOCK 8
5 0010312040 HEX HEAD BOLT 12
5-A 0042512000 WASHER, LOCK 12
6 C3130100003 STATOR ASSY. 1
6-1 0226200495 RUBBER SEAL 1
6-2 8211323004 CLAMPER 1
6-3 0223300172 RUBBER SEAL 1
6-4 8211323103 CLAMPER 1
6-5 0221200440 RUBBER SEAL 1
6-6 0010110035 HEX HEAD BOLT 2
6-6A 0041210000 WASHER, FLAT 2
6-7 C3132200003 COVER 1
6-8 0226000290 RUBBER SEAL 2
6-9 0225000590 RUBBER SEAL 1
6-10 0017106020 HEX HEAD BOLT 6
6-11 0601850144 GROMMET 1
7 C3154000002 END BRACKET 1
8 C3138000003 FIELD ASSY. EXCITER 1
9 0012110080 HEX HEAD BOLT 4
9A 0042610000 WASHER, LOCK 4
9B 0041210000 WASHER, FLAT 4
10 0017112045 HEX HEAD BOLT 4
11 C3154300104 BEARING COVER 1
12 C3154300004 BEARING GASKET 1
GENERATOR ASSY.
