DCA-150SSKII — PARTS AND OPERATION MANUAL— REV. #1 (05/08/01) — PAGE 73
ENGINE OPERATING PANEL ASSY.(CONT)
NO. PART NO. PART NAME QTY. REMARKS
27 8131860303 SET BOARD, OUTPUT TERM. 1
28 0801830304 OUTPUT TERMINAL 5
29 0801830804 HEX HEAD BOLT 5
30 0039316000 HEX NUT 10
31 0040016000 LOCK WASHER 15
32 0041416000 PLAIN WASHER 20
33 011208035 HEX HEAD BOLT ............................ 5 .............REPLACES 0017108035
34 8131865704 COVER OUTPUT TERMINAL 1
35 0605010051 HINGE 2
36 0027103010 MACHINE SCREW 6
37 0027103016 MACHINE SCREW 6
0207003000 HEX NUT 6
38 0017106016 HEX HEAD BOLT 2
39 0845032104 RUBBER COVER 1
40 0845032004 SET FRAME RUBBER COVER 1
41 011008020 HEX HEAD BOLT ............................ 4 .............REPLACES 0017108020
42 0601812597 RECEPTACLE ................................. 2 .............530EM; REPLACES 0601812598
43 0601811034 RECEPTACLE ................................. 3 .............CS6369; REPLACES 0601812565
44 0021304015 MACHINE SCREW ........................ 10 .............REPLACES 0027104015
0030004000 HEX NUT 10
031104080 PLAIN WASHER ............................ 10 .............REPLACES 0041204000
45 06018053136 CIRCUIT BREAKER ........................ 2 .............KM-51265V20A
46 0601805840 CIRCUIT BREAKER ........................ 3 .............KM-52265V50A
47 8131817103 BRACKET CIRCUIT BREAKER 1
47-1 0223300200 RUBBER CUSHION 1
48 011206020 HEX HEAD BOLT ............................ 2 .............REPLACES 0017106020
49 8131865303 COVER 1
50 012212045 HEX HEAD BOLT ............................ 2 .............REPLACES 0010012045
51 031112230 PLAIN WASHER .............................. 2 .............REPLACES 0041212000
52 0805009804 RUBBER WASHER 2
53 0030012000 HEX NUT 2
DCA-150SSKII — ENGINE OPERATING PANEL ASSY.
