DCA-150SSKII — PARTS AND OPERATION MANUAL— REV. #1 (05/08/01) — PAGE 61
DCA-150SSKII— GENERATOR ASSY.
GENERATOR ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 8151000312 ROTOR ASSY ................................ 1 ..........INCLUDE ITEMS W/*
1-1* FIELD ASSY 1
1-2* 8131070013 FAN 1
1-3* 012010030 HEX HEAD BOLT ......................... 12 ..........REPLACES 0012110030
1-4* 030210250 LOCK WASHER............................ 12 ..........REPLACES 0042510000
1-5* 8131611004 COUPLING DISK 8
1-6* 8131015003 BALANCING PLATE 1
1-7* 0012112035 HEX HEAD BOLT 10
1-8* 0042612000 LOCK WASHER 10
1-9* 8101026013 SET PLATE RECTIFIER 1
1-10* 0601821349 RECTIFIER .................................... 2 ..........PT3610
1-11* 0601822601 SURGE ABSORBER...................... 1 ..........ERZ -M14JK621A
1-12* 8001020004 INSULATOR WASHER 1
1-13* 8001020504 INSULATOR WASHER 1
1-14* 0010110020 HEX HEAD BOLT 4
1-15* 0040010000 LOCK WASHER 4
1-16* 0601000209 BALANCING WEIGHT KIT 1
1-17* 0071906312 BEARING 1
2 8151340213 STATOR ASSY 1
3 0845041804 GROMMET 2
4 8131315102 END BRACKET 1
5 8101350013 FIELD ASSY, EXCITER 1
6 0012110060 HEX HEAD BOLT 4
7 0042610000 LOCK WASHER 4
8 031110160 PLAIN WASHER ............................. 4 ..........REPLACES 0041210000
9 0010112035 HEX HEAD BOLT 6
10 0040012000 LOCK WASHER 6
11 031112230 PLAIN WASHER ............................. 6 ..........REPLACES 0041212000
12 8131310114 COVER, BEARING 1
13 8131312214 GASKET, BEARING 1
14 8101331003 COVER, END BRACKET 1
15 0105050616 HEX HEAD BOLT ......................... 10 ..........REPLACES 0017106012
16 8101333003 COVER, END BRACKET 1
17 0010106030 HEX HEAD BOLT 2
18 0040006000 LOCK WASHER 2
19 952404470 PLAIN WASHER ............................. 2 ..........REPLACES 0041206000
20 012010030 HEX HEAD BOLT ......................... 12 ..........REPLACES 0012110030
21 030210250 LOCK WASHER............................ 12 ..........REPLACES 0042510000
22 8131332003 COVER, FAN 1
23 0605000063 RUBBER SUSPENSION 2
24 0030016000 HEX NUT 4
0040016000 LOCK WASHER 4
