L Style Dash
NOTE, Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard equipment.
Ref.
No.
Part No. Description
1 951-04304 Fuel Tank, 1.36 Gal.
2 710-05070 Screw, Tap, 1/4-20, 0.500
3 726-0230 Cable Tie, 36.0 Long
4 751-12089-28 Hose Vent
5 951-12179A Fuel Cap, 2.25”
6 783-07083 Gas Tank Support Bracket
7 735-04081 Rubber Grommet, 23 x 3.55
8 751-12118 Rollover Valve
9 710-05237 Hex Screw, 1/4-20 x 1.50
10 710-1652 Tap Screw, 1/4-20, 0.625
11 710-3144 Hex Screw, 3/8-16, 2.00, Gr5, Std
12 712-04065 Flange Lock Nut, 3/8-16
13 731-07885B Shift Lever
14 731-07895A Index Control
15 732-04877 Compr. Spring, .685 OD x .63
16 736-3006 Lock Washer, 1/4
17 747-05398 Speed Selector Control Rod
18 750-04465C Flange Spacer, .390 X .671 X 1.095
19 783-06823 Speed Latch
20 731-05265 Choke Plug
21 931-08542A Dash, Upper
22 746-04367 Throttle/Choke Cable Assembly
23 625-05002 Key, Assembly
24 783-06991 Speed Latch - No RMC
25 910-0224 Screw, #10-16 x .500
26 710-0604A Tap Screw,5/16-18, 0.625
27 710-3025 Hex Screw, 5/16-18 x .625
28 712-04063 Flange Lock Nut, 5/16-18
29 741-0587 Bearing, .628 ID x 1.36
30 783-06785A Bracket, Steering Support
31 783-06811 Dash, Lower NWNDW
32 925-04659 3 Position Key Switch
— 725-04849C Harness, LT-5, NRMC,Dual
7
