38” Deck
NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard equipment.
Ref. Part Number Description
1 918-04474A 5.75" Pulley Spindle Assembly
2 683-04138B Deck Brake Assembly
3 983-04167 Deck Brake Assembly
4 683-0254B LH Deck Hanger Bracket
5 983-04263 38" Deck Assembly
6 710-0347 Hex Screw, 3/8-16 x 1.75
7 710-04484 Screw, 5/16-18 x .750
8 710-0528 Hex Screw, 5/16-18 x 1.25
9 710-0778 Screw, 1/4-20 x 1.50
10 710-3005 Hex Screw, 3/8-16 x 1.25
11 710-3008 Hex Screw, 5/16-18 x .75
12 710-0751 Hex Screw, 1/4-20 x .62
13 750-1000 Spacer, .80 x 1.10 x 1.322 LG
14 712-04063 Flangelock Nut, 5/16-18
15 712-04065 Flangelock Nut, 3/8-16
16 712-0417A Flange Nut, 5/8-18
17 712-04064 Flangelock Nut, 1/4-20
18 712-04243 Flangelock Nut, 1/2-13
19 914-0104 Cotter Pin, .072 Diameter
20 917-04074 Deck Adjuster Gear
21 726-0233 Push Nut, .25 x .50
Ref. Part Number Description
22 732-04280B Extension Spring, .75 x 6.375
23 732-04287 Extension Spring, .500 x 6.375
24 936-0119 Lock Washer, 5/16
25 756-1188 Deck Pulley, 5.75
26 783-07236 Pulley Cap
27 738-04162C Shoulder Spacer, .8840 x .190
28 738-04166 Shoulder Spacer, .5000 x .1475
29 942-0610A 3 in 1 Blade
30 747-04322 38" Front Adjust Deck Rod
31 783-04602A Belt Cover
32 747-04381 38" Brake Control Rod
33 748-04069 Deck Lift, Pivot Cup
34 750-0566A Spacer, .260 x .375 x 1.030
35 954-04062 V Type Belt
36 756-04129B Idler Pulley
37 783-04740 Deck Engage Cable Bracket
38 931-1032B Chute Assembly
39 938-04241 Spindle Shaft, 5.50
40 941-0919A Ball Bearing, .787ID x 1.85 OD x .551
41 750-04739 Spacer, .820 x 1.150 x .480 LG
23
