Ref. Part Number Description
1 710-05070 Screw, 1/4-20 x .500
2 710-04484 Screw, 5/16-18 x .750
3 710-0599 Screw Pan Torx Head, 1/4-20 x .500
4 731-04591A Cup Holder
5 736-0607 Loack Washer, 5/16
6 783-04587D Fender
7 783-04843 Lift Adjuster Bracket
8 783-1489D Seat Mount Bracket
9 712-04063 Flangelock Nut, 5/16-18
10 732-1184 Extension Spring
11 936-0108 Flat Washer, .510x .750 x .033
12 736-0242 Bell Washer, .340 x .872 x .060
13 938-0296 Shoulder Screw, 5/16-18 x .437 x .268
14 783-0209D Lift Seat Bracket
15 783-04081D Pivot Seat Manual Adjust Bracket
16 710-04482 Hex Head Flange, 3/8-16 x .875
17 710-0134 Screw Carriage, 1/4-20 x .62
18 720-04061 Knob, 3/8-16 x .875
19 735-04047 Foot Pad, LH
723-04026 Foot Pad, Abrasive, LH
20 735-04048 Foot Pad, RH
723-04025 Foot Pad, Abrasive, RH
21 726-3046 Ratchet Clip, .250 x .500
22 710-0227 Screw, 8-18 x .500
23 726-0279 Insulator Plate
24 925-1303 Outer Seat SPring
25 726-0278 Insulator Boss Plate
26 725-1439 Inner Seat Spring
27 757-04083A Medium Back Seat, Black, Set-up B
757-04099 Low Back Seat, Black, Set-up B or C
757-04088A High Back Seat, Set-up B
NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard equipment.
Seat and Fender
19
