Ref. Part Number Description
1 683-04195 Support Bracket
2 683-04649A Frame Assembly
3 710-0134 Screw Carriage, 1/4-20 x .62
4 710-04484 Screw 5/16-18 x .750
5 710-0599 Screw, 1/4-20 x .500
6 710-3008 Hex Screw, 5/16-18 x .75
7 712-04063 Flangelock Nut, 5/16-18
8 712-04064 Flangelock Nut, 1/4-20
9 912-0429 Hexlock Nut, 5/16-18
10 732-04035 Compression Spacer, 1.28 x 3.125
11 736-0173 Flat Washer, .28 x .74 x .063
12 738-04237A Shoulder Spacer, 10-32 x .500
13 783-04548D Seat Frame Bracket
14 783-04637 Running Board Bracket
15 783-04753 Support Frame Bracket
16 783-04869A Battery Bracket
17 710-04666 Hex Head Flange, 1/4-20 x .75
18 712-0271 Sems Nut, 1/4-20
19 925-1707D 230 CCA Battery
20 783-04536B Support Bracket
21 647-04096A PTO Handle Assembly
22 683-04155A Lift Assembly, 38/42"
23 712-04065 Flangelock Nut, 3/8-16
24 714-04040 Bow-tie Cotter Pin
25 716-0106A E Ring
Ref. Part Number Description
26 720-0311 Handle Grip, 1/2
27 732-04225 Torsion Spring
28 738-04130 Shoulder Bolt, 3/8-16 x .625 x .175
29 941-0225 Hex Flange Bearing
30 747-04282 Deck Lift Handle 38”
747-05296 Deck Lift Handle 42”
31 747-04393 Lift Rod
32 783-04494C 38/42" Lift Arm, RH
33 783-04711C 38/42" Lift Arm, LH
34 725-04363 Switch Interlock
35 736-0322 Flat Washer, .450 x 1.250 x .164
36 741-04119A PTO Bearing
37 946-04173E Deck Engage Cable
38 756-04196A Engine Pulley, 3.39 x 6.12
39 683-04448 Battery Hold Down Rod
40 936-0300 Flat Washer, .406 x .875 x .059
41 710-0604A Screw, 5/16-18.0 x .625
42 725-04439 12V Solenoid
43 925-04039 Screw Mount Interlock Switch
44 710-3157A Hex Screw, 7/16-20 x 3.25
45 914-0145 Click Pin, .092 x 1.64
46 720-04049A Handle Grip, 3/8
47 732-04276A PTO Spring Extension
48 747-04332A 38" Belt Keeper
747-04857 42" Belt Keeper
NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard equipment.
15
Frame and PTO Lift
