iOptron 70AZ Telescope User Manual



3
1. Telescope Assembly
1.1. iExplore 70AZ Assembly Terms
1
2
4
5 6
7
10
8
12
11
13
3
9
Figure 1. iExplore 70AZ
(1). Optical tube assembly (OTA)
(2). Finderscope
(3). Finderscope mounting socket
(4). Eyepiece
(5). Diagonal
(6). Focusing knob
(7). Altitude adjustment rod
(8). Accessory tray
(9). Tripod support bracket
(10). Tripod legs
(11). Yoke (altazimuth) mount
(12). Altitude lockig knob
(13). Azimuth locking knob
Parts shown in Figure 2
(14). Tripod leg attachment bolts (3 sets)
(15). Tripod locking screws (3 sets)
(16). 3X Barlow lens
(17). 1.5X Erecting eyepiece
