4. Technical Specifications
Mount AltAzimuth
Optical Design Achromatic Refractor
Objective Lens Air-spaced, fully coated
Clear Aperture 70 mm
Focal Length 700mm
Focal Ratio f/10
Focuser
Rack-and-pinion, accepts 1.25" eyepieces and
accessories
Eyepiece 4mm, 12.5mm, 20mm
Diagonal 90º mirror, 1.25”
Magnification with
supplied eyepiece
35X (w/ 20mm),
56X (w/12.5mm)
175X (w/4mm)
Barlow Lens 3X
Erecting Eyepiece 1.5X
Finding Scope 5X24
Tripod Aluminum
Total Weight 6 lbs.
Warranty One year limited
May 2011 V1.0
iOptron reserves the rights to revise this instruction without notice. Actual color/contents/specfication may differ from those described
in this instruction.
