SKU 91142 For technical questions, please call 1-800-444-3353. Page 5
Unpacking
When unpacking, check and make sure that the following parts are included. If any parts
are missing or broken, please call Harbor Freight Tools at the number on the cover of this
manual as soon as possible.
Upper Bracket (3A)
Engine (4A)
Pump (5A)
Bracket Screw (12A)
High Pressure Hose (1A)
Spray Gun Nozzle (13A)
Spray Gun (2A)
Bracket Screw (12A)
Bottom Bracket (7A)
Water Outlet Connector (9A)
Assembly
1. Insert the Upper Bracket (3A) onto the Bottom Bracket (7A) and secure with Bracket
Screws (12A) as shown above. Tighten securely.
2. Screw on the High Pressure Hose (1A) to the Water Outlet Connector (9A). Tighten
securely.
3. Screw on the other end of the High Pressure Hose to the Spray Gun (2A) handle.
Tighten securely.
4. Attach the Spray Gun Nozzle (13A) to the Spray Gun (2A). Tighten securely.
