SKU 91142 For technical questions, please call 1-800-444-3353. Page 10
Pump Assembly Parts List
Item
Description Qty.
1 Adjusting Cap, PA66 1
2 High Pressure Screw Cap, 59-1 1
3 Adjusting Spring, 65 Mn 1
4 Valve Core, 59-1 1
5 O-ring, ¢11x1.9 1
6 Junction Screw Cap, 59-1 1
7 O-ring, ¢22x1.9 1
8 O-ring, ¢9x1.9 1
9 O-ring, ¢16x1.9 1
10 Air-proof Ring, 59-1 1
11 Pressing Group Cap, 59-1 1
12 Pump Head, Y104 1
13 Bolt, M8x30 2
14 O-ring, GB1235-76, ¢14x1.9 6
15 Valve, Water Inlet-Outlet, POM 6
16 O-ring, GB1235-76, ¢16x1.9 4
17 Cap, Water Inlet Valve, 59-1 4
18 Bolt, M8x36 1
19 O-ring, GB1235-76, ¢10x1.9 1
20 Housing, Water Inlet, Y104 1
21 Bolt, M6x25 4
22 Bolt, M8x25 4
23 Joint, Water Inlet, PA66 1
Item
Description Qty.
24 Filter Screen, 1Cr18Ni9 1
25 Valve, Unilateral, 1013B 1
26 Spring, Unilateral Valve, 4Cr13 1
27 O-ring, ¢22x2.4 1
28 Joint, Water Outlet, 59-1 1
29 Pump Body, Y104 1
30 O-ring, ¢86x2.4 1
31 Bolt, M8x25 1
32 Gasket, M8 4
33 Bearing 1
34 Bearing, 303 1
35 Seal, Oil Frame, NBR 1
36 Drive Shaft, 45# 1
37 Base, Y104 1
38 V-ring, NBR 3
39 O-ring, GB1235-76, ¢18x1.9 3
40 Ring, Interspace, 59-1 3
41 O-ring, GB1235-76, ¢28x2 3
42 Ring, Interspace Separating, 59-1 3
43 Seal, Frame Oil, NBR 3
44 Spring, Plunger, 65Mn 3
45 Plunger, 2Cr13 3
46 Plunger Clip, 65Mn 3
Note: Some parts are listed and shown for illustration purposes only and are not available individu-
ally as replacement parts.
