SKU 91142 For technical questions, please call 1-800-444-3353. Page 2
Specications
Gas Engine
Robin , OHV Engine 6 HP, unleaded gas, recoil, 3400 RPM, low oil shut-
down; Oil capacity: 20 oz. (0.6 L); Gas capacity: 4 quarts (3.8 Liter) Refer to
the Robin maintenance manual for further details
Pressure Washer Gun
2900 PSI Maximum, Safety trigger activated gun, 60 -140 Deg .F . Temp.
Maximum ( use cold water only).
Water Pressure 2,200 PSI rated, 2.500 PSI maximum
Water Output 2.2 GPM maximum; unloader valve
Water Supply Requirements 3+ GPM recommended; 1.62 GPM minimum
High Pressure Hose 27 feet
Water Nozzle
Safety Trigger Handle with lock-off, spray output adjustment; 150-Bar/2,175
PSI
Wheels 2 - Pneumatic wheels
Garden Hose Fitting Quick connect, tting coupler, ¾ inch I.D.
Save This Manual
You will need the manual for the safety warnings and precautions, assembly instructions,
operating and maintenance procedures, parts list and diagram. Keep your invoice with this
manual. Write the invoice number on the inside of the front cover. Keep the manual and
invoice in a safe and dry place for future reference.
Safety Warnings and Precautions
WARNING: When using tool, basic safety precautions should always be followed to
reduce the risk of personal injury and damage to equipment.
Read all instructions before using this tool!
Keep work area clean. Cluttered areas invite injuries.
Observe work area conditions. Keep work area well lighted. Do not use powered tools in
the presence of ammable gases or liquids.
Keep children away. Children must never be allowed in the work area. Do not let them
handle machines, tools, or extension cords.
Store idle equipment. When not in use, tools must be stored in a dry location to inhibit
rust. Always lock up tools and keep out of reach of children.
Use the right tool for the job. Do not attempt to force a small tool or attachment to do the
work of a larger industrial tool. There are certain applications for which this tool was de-
signed. It will do the job better and more safely at the rate for which it was intended. Do not
modify this tool and do not use this tool for a purpose for which it was not intended.
Dress properly. Do not wear loose clothing or jewelry as they can be caught in moving
parts. Protective, electrically non-conductive clothes and non-skid footwear are recom-
mended when working. Wear restrictive hair covering to contain long hair. Wear protective
boots able to withstand high pressure water contact.
1.
2.
3.
4.
5.
6.
