WARNING
If you do not understand how a specific control
functions, or have not yet thoroughly read the
FEATURES & CONTROLS section, do so now.
Do NOT attempt to operate the tractor without
first becoming familiar with the location and
function of ALL controls.
STARTING THE ENGINE
1. Engage the parking brake and make sure the PTO
switch is disengaged and the motion control lever
is in the NEUTRAL position.
2. Set the engine throttle control to FULL throttle
position. Then fully close the choke by pulling the
knob OUT fully.
NOTE: A warm engine may not require choking.
3. Insert the key into the ignition switch and turn it to
the START position.
4. After the engine starts, gradually open the choke
(push knob down fully). Reduce to half throttle
speed and allow to warm up.
Warm up the engine by running it for at least a minute
before engaging the PTO switch or driving the mower.
5. After warming the engine, ALWAYS operate
the unit at FULL THROTTLE when mowing.
In the event of an emergency the engine can be
stopped by simply turning the ignition switch
to STOP. Use this method only in emergency
situations. For normal engine shut down follow the
procedure given in STOPPING THE MOWER
Operation
STOPPING THE MOWER
1. Gently squeeze both steering control levers evenly
to stop the machine.
3. Once the machine is stopped, firmly depress the
neutral return pedal to place the transmissions in
neutral.
2. Disengage the PTO by pushing down on the PTO
switch.
3. Engage the parking brake by pulling the handle up
and back until it stops.
4. Move the throttle control to mid-throttle position
and turn the ignition key to OFF. Remove the key.
