- 10 -
2.9 MOWER DECK
2.9.1 Model Numbers: Serial Nos. 320,000 and higher: FMD604 and FMD524
NOTE: Turf Tracer units 320,000 and higher can only be used with FM604
and FMD524 units.
2.9.2 Cutting Width: 60 in. (152.4 cm.)
52 in. (132.1 cm.)
2.9.3 Discharge: Right Side
2.9.4 Optional Mulch Kit and Bagger available.
2.9.5 Blade Size: 60" - (3 ea.) 20.50 in. (52.1 cm.)
52" - (3 ea.) 18.00 in. (45.7 cm.)
2.9.6 Type of Drive: Electric clutch mounted on engine shaft. Blades driven by two
belts with self tensioning idlers.
2.9.7 Adjustable anti-scalp rollers(6 ea.)
2.9.8 Cutting Height: Adjusts in 1/2” (1.3 cm) increments from 1 1/2” (3.8 cm) to 4
1/2” (11.5 cm).
2.9.9 Deck Mounting: Full floating deck is attached to out-front support frame,
removable for service.
2.10 DIMENSIONS
2.10.1 Overall Width:
w/52” Deck w/60” Deck
Discharge chute down
64.2” (163.1 cm) 72.2” (183.4 cm)
Discharge chute up (Transport only)
53.4” (135.6 cm) 61.4” (156.0)
2.10.2 Overall Length:
w/52” Deck w/60” Deck
Overall Length
83.4” (211.8 cm) 83.4” (211.8 cm)
2.10.3 Curb Weight:
w/52” Deck w/60” Deck
Total weight∗
∗∗
∗
720 lbs. (327 kg) 760 lbs. (345 kg)
∗ Weights will vary slightly depending on engine option.
2.10.4 Overall Height: 45” (114.3)
2.10.5 Tread Width (to outside of tires): 45.8” (116.3 cm)
2.11 TORQUE REQUIREMENTS
BOLT LOCATION TORQUE
Cutter Housing Spindle Nut ............................................. 75-80 ft/lbs.
Blade Mounting Bolt..................................................... 115-120 ft/lbs.
Mower Deck Support/Engine Deck Mount ........................30-35 ft/lbs.
Anti-Scalp Roller Bolts ......................................................40-45 ft/lbs.
Engine Mounting Bolts......................................................15-20 ft/lbs.
Wheel Lug Nuts ...............................................................90-95 ft/lbs.
3. ASSEMBLY INSTRUCTIONS
3.1 UNCRATE UNIT
3.1.1 Remove tractor and mower deck from crates.
3.2 SERVICE BATTERY:
The machine is shipped with a wet battery.
WARNING: Battery posts, terminals, and related accessories contain lead compounds, chemicals known
to the State of California to cause cancer and reproductive harm. Wash hands after handling.
