ENGINE DECK GROUP
- 6 -
Ref.
No.
Qty.
Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1 1-807019 Key, woodruff 1 x 1/4........ 2
35
1-807272 Key, 5mm sq. x 25mm...... 2
2
1-803040 Nut, slotted 3/4-16............ 2
36
322-7 Screw, 5/16-18x1½ HHCS. 3
3
1-806800 Pin, cotter 9/64 x 1-1/2..... 2
37
1-603044 Bushing - Idler pivot .......... 1
4
242-50 Nut, wheel 1/2-20 ............ 8
38
3290-357 3/8-16 Whizlock Nut.......... 19
5
1-413473 Tire & Wheel Assembly.... 2
39
1-653035 Pulley, pump drive............. 1
1-413474 Tire 16 x 6.50-8................ 1 40
1-402113-01 Deck, engine wldmt .......... 1
1-603715 Wheel............................... 1 41 1-809062 Bolt, .500 x 1.75(shoulder) 1
6
1-602997 Hub,tapered(4 bolt)w/stds 2
42
302-40 Zerk................................... 1
1-633926 Stud, wheel 1/2-20 ........... 8 43 1-322108 Bellcrank assy. w/zerk ...... 1
7
3234-12 Screw, whizloc 3/8-16x3/4 8 1-322086-01 Bellcrank weldmt............... 1
8
323-6 Screw, 3/8-16 x 1.............. 8 44 1-806003 Hairpin............................... 2
9
98-5975 Washer, 3/8 spring disc.... 8
45
1-323172 Linkage, blade engmnt. .... 1
10
1-322162-01 Mount, motor (36”) ........... 2 46 3296-29 Nut, nylock 5/16-18 ........... 3
1-402062-01 Mount, motor (48”) ........... 2 47 1-323245 Spring, compression......... 1
11
1-523157 Washer, spacer................ 2 48 1-322090-01 Bellcrank........................... 1
12
1-373034 Washer, swivel................. 2 49 322-10 Screw, 5/16-18 x 2............ 1
13
1-303334 Washer, 5/16 spring disc.. 4 50 1-513051 Switch, blade engagement 1
14
1-603610 Washer, 7/16 spring disc.. 2 51 3296-2 Nut nylock 10-24 ............... 3
15
1-403160 Sheave, blade drive (48”) . 1 52 1-323213 Bracket, switch.................. 1
1-643292 Sheave, blade drive (36”) . 1 53 3290-500 Screw, 10-24 x 5/8............ 2
16∇
30-1710 Setscrew, 5/16-18 x 1....... 1 54 321-3 Screw, 1/4-20 x 5/8 ........... 2
17
1-807259 Key, 1/4 sq. x 1................. 2 55 3212-6 Screw, 7/16-20 x 1 1/2 ...... 1
18∇
1-803050 Setscrew, 5/16-18 x 3/4.... 1 56 3256-24 Washer, 3/8 (SAE)............ 1
19∇
1-803310 Setscrew, 5/16-18 x 3/8.... 2 57 32128-33 Nut, whizlock 1/4-20.......... 2
20
1-603843 Idler, pulley....................... 1 58 3256-23 Washer, 5/16 flat............... 2
21
1-603496 Bushing, idler.................... 1 59 322-3 Screw, 5/16-18 x 3/4 ......... 2
22
3231-29 Screw, 3/8-16 x 1-3/4 ....... 1 60 323-4 Screw, 3/8-16 x 3/4 ........... 2
23
3253-5 Lockwasher, 3/8 ............... 1 61 1-633068 Arm ................................... 1
24
323-12 Screw, 3/8-16 x 2-1/2 ....... 1 62 1-323607 Shield, Trailing ................. 1
25
1-373034 Washer, swivel................. 1 63 302-19 Zerk, 1/4-28 STRT ............ 1
26
1-513034 Bearing, pivot ................... 2 64 323-11 Screw, 3/8-16 x 2 1/4 ........ 1
27
1-602521-01 Arm, assy idler (w/brgs) ... 1 65 1-323366 Split ring............................ 1
1-602458 Arm, assy idler (w/o brgs). 1
66 3296-39 Nut, 3/8-16 nylock ............. 1
28
1-603402 Spring, extension.............. 1 67 323-23 Screw, 3/8-16 x 4 1/2 ........ 1
29
322-5 Screw, 5/16-18 x 1............ 1 68 1-323365 Chain, twist link ................. 1
30
1-603801 Anchor, spring.................. 1 69 3256-14 Washer, #10...................... 1
31
32128-20 Nut, whizlock 5/16-18....... 6 70 1-809069 Screw, 10-24x7/8HxSktHd 1
32
1-653163 Belt, pump drive ............... 1 71 1-413510 Clip, loom 1/2.................... 2
33∇
1-803050 Setscrew, 5/16-18 x 3/4.... 4 72 323-13 Screw, 3/8-16 x 2 3/4 ........ 3
34
1-413010 Sheave - pump................. 2 73 322-9 Screw, 5/16-18 x 1 ¾…….. 1
74 1-322110 Guide,Belt………………….. 1
Use anti-seize compound on pulley bore.
∇ Use Pro-Lock (nut type, Part no. 1-840022, 5 ml tube) on setscrew threads.
Exmark red touch up spray paint - P/N 1-850337
