36” MOWER DECK
- 2 -
Ref.
No.
Qty.
Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1★ 1-304267 Front Deck w/decals & dogleg....…1 39 1-323729 Powder metal bearing .................. 2
1-302235-01 Deck weldmt .................................1 40 323-4 3/8-16 x 3/4 HH capscrew ........... 8
2 1-302189-01 Baffle wldmnt, dogleg....................1 41 1-603843 Idler pulley (heavy duty)............... 1
3 322-2 Screw, 5/16-18 x 5/8 .....................7
42∗
1-324265 Cutter Housing Complete ........... 2
4 32128-20 5/16-18 Whizlock nut................... 23 43 322-5 5/16-18 x 1 HH capscrew............ 2
5 1-324408 Engagement arm w/bushing (36”).1 44 1-633573 Guard, bottom ............................. 2
6 302-52 Grease Zerk, 1/8 NPT straight......2 45 32120-8 Retaining ring .............................. 2
7 302-19 Grease Zerk, 1/4-28 straight....... 1
46∇
1-513016 Bearing ........................................ 4
8 1-323385 Knob, belt cover.......................... 4 47 1-323532 Cutter housing ............................. 2
9 1-809020 Quick pin, 10" caster ................... 2 48 1-303314 Spacer, 10” caster....................... 8
10 3296-29 5/16-18 Nyloc hex nut................. 2 49 1-323529 Tube, spindle............................... 2
11 323-6 3/8-16 x 1 HH capscrew .............. 6 50 1-323528 Spacer ........................................ 2
12 3290-357 3/8-16 whizlock nut ......................14 51 1-303514 Flange , thrust bearing ............... 4
13 1-323748 Ring, push-on 7/16 .......................1 52 1-323339 Retaining washer, sheave ........... 2
14 98-5975 3/8 Disc spring washer .................7
53∇
1-403183 Pulley........................................... 2
15 1-808280 5/16 x 1 Clevis pin.........................1 54 3219-6 5/8-18 UNF hex nut..................... 2
16 1-303105 Yoke..............................................1 55 1-800861 5/8-18 x 8 HH Capscrew (Gr 5)... 2
17 1-806003 Cotter hairpin............................... 3 56 1-807267 Key, 1/4 x 3/16 x 1 1/4................. 2
18 32151-103 E-Ring for .875 rd........................ 1 57 1-323539 Spacer, blade drive...................... 8
19 323-10 3/8-16 x 2 capscrew.................... 1 58 1-513208 5/8 Spring disc washer................ 2
20 1-633482 Blade, Notched air foil (36") ........ 2 59 1-303434 Engagement bushing.................. 1
1-613251 Blade, Solid air foil (36").............. 2 60 1-303348 Eye bolt (left hand thread)........... 1
•
1-633484 Blade, Mulching (36") .................. 2 61 1-303236 Turnbuckle body.......................... 1
1-633485 Blade, Low Lift (36") optional....... 2 62 1-303238 Eye bolt (right hand thread)......... 1
21 1-513338 Washer, special .......................... 2 63 1-322235 Assist arm (36”)........................... 1
22 3253-7 1/2 spring lockwasher ................. 2 64 322-10 Screw, 5/16-18 X 2 ...................... 1
23 3217-9 1/2-13 Hex nut............................. 2 65 1-323303 Assist arm linkage....................... 1
24 325-20 1/2-13 x 6 HH capscrew.............. 2 66 1-322153 Caster/mount, complete.............. 1
25 1-303352 Washer, spindle .......................... 1 67 1-302203 Caster wheel support w/bearings 2
26 1-513648 Wheel & tire, complete................ 2 68 1-302194-01 Caster wheel support wldmnt...... 2
1-513807 Wheel & hub................................ 1 69 1-303334 5/16 Spring disc washer .............. 8
1-513808 Tire, 9 x 3.50-4 4-ply ................... 1 70 1-323533 Spacer ......................................... 2
1-513809 Roller bearing.............................. 1 71 1-634619 Housing w/Brg, Spacer and Ring 2
1-513810 Bushing........................................ 2 72 3256-3 Wshr, flat std 5/16 ....................... 1
27 1-323735 Drive belt (to blades) 36" Model.. 1 73 1-323715 Rod, brake 36”............................. 1
♦28
1-803310 Setscrew, 5/16-18 x 3/8 .............. 2 74 1-323071 Spring.......................................... 1
29 322-6 5/16-18 x 1 1/4 HH capscrew ..... 9 75 1-323747 Spring, compression ................... 1
30 1-513547 Spacer, front caster..................... 2 76 1-323746 Spacer, flanged .......................... 2
31 1-303537 Stud, belt shield (short) ............... 2 77 3296-42 Nut, nyloc ¼ - 20 ......................... 2
32 1-303536 Stud, belt shield (long)................. 2 78 1-324372 Pad/spring assy........................... 1
33 1-302218 Kit,shield w/decals 36”................. 1 79 321-4 Screw, HHCap ¼-20 X 3/4.......... 2
1-302213-01 Shield weldmt, 36" ..................... 1 81 1-403179 Tube, pivot................................... 1
34 1-323417 Washer, belt cover mount........... 4 82 3256-23 Wshr, flt SAE 5/16....................... 1
35 1-322145-01 Fork wldmnt, caster..................... 2
83 32120-35 E-ring .......................................... 1
36 1-322154 Caster wheel assembly............... 2
37 1-302233-01 Chute........................................... 1
38 3296-56 Nut, nyloc ¼-20 thin..................... 1
♦ Use Pro-lock Nut Type (p/n 1-840022 .5 ml tube) on the setscrews
• Requires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N MK362(36”)
∗ Cutter housing complete includes sheave, washer, and nut and does not include blade.
★ Deck weldment does include welded in flow control baffles.
∇ Use antisieze on bore of sheaves & bearings
Exmark red touch up spray paint - P/N 1-850337
