UPPER HANDLE and CONTROLS
- 10 -
Ref.
No.
Qty.
Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1 103-0212 Handle w/decals(1-322226).1
38
1-303022 Fuel line, 8.5" ..................... 1
2
1-303097 Grip, handle........................ 2
39
Kawasaki PN 49019-1055 fuel filter
3
1-612168 Latch, thumb w/grip (RH) ... 1 with 6.0” fuel line ................ 1
ƒ
1-612167 Latch, thumb w/grip (LH).... 1
40
1-403121 Switch, on/off w//key.......... 1
4
1-303019 Grip, latch........................... 2
41
1-413179 Tank, gas........................... 1
5
1-303435 Washer, 1/4 spring disc ..... 6
42
1-513508 Cap, gas............................. 1
6
321-10 Screw, 1/4-20 x 1-3/4......... 2
43
1-543296 Grommet............................ 1
ƒ
1-412159-03 Lever, drive (LH) ................ 1
44
1-323430 Module, Interlock ............... 1
7
1-412161-03 Lever, drive (RH)................ 1
45
321-3 Screw, ¼-20 x 5/8.............. 3
8
1-603749 Bushing, drive lever............ 2
46
1-303287 Tie, plastic 5 1/2” (Kaw)..... 5
9
1-806003 Hairpin................................ 5
47
1-303335 Tie, plastic 7 5/16” ............. 2
10
32128-33 Nut, whizlock 1/4-20........... 5
48
1-403181 Harness wiring (Kawasaki) 1
11
1-807513 Screw, #10-24x½ carriage . 2
49♦
1-803322 Setscrew, 5/16-24 x 5/16... 2
12
321-9 Screw, 1/4-20 x 1-1/2......... 2
50∇
1-412185-03 Lever, OPC (RH) ............... 1
13
1-633349 Spring, fuel tank ................. 2
51
1-303365 Bushing, nylon ................... 2
14∇
1-633023 Stud, fuel tank .................... 2
52
1-322192-03 Rod weldmt, connecting .... 1
15
1-613055 Pin, clevis ........................... 2
53
322-3 Screw, 5/16-18 x 3/4.......... 2
16
1-413152 Bearing............................... 4
54∇
1-412183-03 Lever, OPC (LH)................ 1
17
1-513051 Switch................................. 2
55
1-603727 Clip, .56 Loom.................... 1
18
1-633181 Plate, tapped ...................... 1
56
3296-2 Nut, nylock #10-24............. 2
19
1-303363 Spring, actuator.................. 1
57♦
1-603175 Knob, 1-3/8 ........................ 1
20
1-323134 Knob, (push/pull)................ 1
58
3296-29 Nut, nylock 5/16-18............ 2
21
3218-2 Nut, jam 5/16-18................. 1
59
1-323245 Spring, compression.......... 2
22
1-323143 Bushing, nylon .38 I.D. ....... 1
60
1-602733 Lever, shift ......................... 1
23
1-323142 Push Nut (.50 shaft) ........... 1
61
3256-23 Washer, 5/16 SAE ............. 5
24
3296-42 Nut, nylock 1/4-20 .............. 3
62
1-323244 Washer, friction.................. 2
25
1-323181 Linkage, blade push/pull .... 1
63
1-603730 Plate, shift lever ................. 1
26
323-6 Screw, 3/8-16 x 1 ............... 4
64
1-603716 Washer, friction.................. 1
27
98-5975 Washer, 3/8 spring disc ..... 4
65
322-10 Screw, 5/16-18 x 2............. 2
28
1-323229 Clip, loom 3/8” (Kaw).......... 1
66
1-323522 Rod, speed control............. 1
29
3256-2 Washer 1/4” std flat........... 3
67
3220-2 Nut, jam 5/16-24 ................ 1
30
3296-47 Nut, nyloc thin 5/16............. 2
68
1-808280 Pin, clevis........................... 1
31
3290-357 Nut, whizlock 3/8-16........... 4
69
1-303105 Yoke, adjustable ................ 1
32
1-804002 Nut, Sq Reg 10-24 ............. 2
70
1-513592 Knob, red ball..................... 1
33
1-513645 Bushing, fuel valve............. 1
71
1-413428 Cable, throttle (15hp Kaw) . 1
34
1-543277 Elbow, fuel tank.................. 1
72
321-4 Screw, 1/4-20 x 3/4............ 1
35
1-303077 Clamp, gas line .................. 4
73
1-805005 Washer, 5/16 lock.............. 2
36
1-603955 Fuel line, 6" ........................ 1
74
3290-500 Screw, #10-24 x 5/8........... 4
37
1-603770 Valve, gas........................... 1
75
103-0219 Asm,Drive Lever RH ..……. 1
103-0218 Asm,Drive Lever LH ………. 1
ƒ Not Illustrated.
♦ Use Pro-Lock ,nut type (Part no. 1-840022 on setscrew threads and on shifter knob threads.
∇ Use Pro-lock, retaining type (Part no. 1-840023 .5cc tube) on inside bore of OPC hub and on fuel tank studs.
Apply dielectric grease on all electrical connectors.
Exmark black touch up spray paint - Gloss black
