Operation
To turn left or right, pull one of the steering levers
back toward neutral in the direction desired.
The machine will move faster the farther the
speed control lever is moved away from neutral.
4. To stop, pull the speed control lever back to the
neutral position.
Driving in Reverse
1. To move rearward in a straight line applying equal
pressure pull both steering levers rearward.
To turn left or right, release pressure on the
steering lever toward the direction desired.
2. To stop, release the steering levers to the neutral
position.
Emptying Hopper
1. A full hopper is indicated by a buzzer located
behind the operator in the hopper. Empty hopper
when buzzer sounds to prevent clogging of the
blower or deck.
2. Disengage PTO, move speed control to neutral,
set park brake and dismount unit to dump hopper.
3. Make sure unit is on a dry level surface.
4. Lift the rear door up and allow it to rest on top
of hopper.
5. Dump hopper by rmly grasping one of the
hopper handles on either side of the unit and
lifting the hopper.
Clearing Hopper Screen
Screen may be removed by rmly lifting screen
handles (see Figure 5).
Pull screen towards the back to remove. Gently tap
debris from the screen as needed.
Excessive build-up on the screen can cause the
blower to plug.
Note: In conditions where the screen clogs quickly,
the front removable screen panel can be turned and
reinstalled under the primary screen to allow free air
ow from the hopper.
Figure 5
1. Front removable screen
can be rotated and
stored for wet condtions
3. Primary screen
2. Front removable screen 4. Handles.
Transporting
Transporting a Unit
Use a heavy-duty trailer or truck to transport the
machine. Lock brake and block wheels. Securely
fasten the machine to the trailer or truck with straps,
chains, cable, or ropes. Be sure that the trailer or truck
has all necessary lighting and marking as required by
law. Secure a trailer with a safety chain.
CAUTION
This unit does not have proper turn
signals, lights, reective markings, or a
slow moving vehicle emblem. Driving on a
street or roadway without such equipment
is dangerous and can lead to accidents
causing personal injury. Driving on a street
or roadway without such equipment may also
be a violation of State laws and the operator
may be subject to trafc tickets and/or nes.
Do Not drive a unit on a public street or
roadway.
20
