Specications
• Cutting Height Adjustment:
Foot activated lever is used to adjust the cutting
height from 1 1/2 inch (3.8 cm) to 4 1/2 inches
(11.4 cm) in 1/4 inch (6.4 mm) increments.
• Mulching Kit: Optional.
Dimensions
Overall Width:
48 inch Deck 52 inch Deck
Without Deck 45.7 inches
(116.1 cm)
45.7 inches
(116.1 cm)
Deector Up 51.8 inches
(131.6 cm)
56.3 inches
(143.0 cm)
Deector Down 59.6 inches
(151.4 cm)
64.8 inches
(164.6 cm)
Overall Length:
48 inch Deck 52 inch Deck
Roll Bar - Up 79.2 inches
(201.2 cm)
79.2 inches
(201.2 cm)
Roll Bar - Down 80.9 inches
(205.5 cm)
80.9 inches
(205.5 cm)
Overall Height:
Roll Bar - Up Roll Bar - Down
69.5 inches (176.5 cm) 45.8 inches (116.3 cm)
Tread Width: (Center to Center of
Tires, Widthwise)
48 inch Deck 52 inch Deck
Drive Wheels 36.2 inches
(91.9 cm)
36.2 inches
(91.9 cm)
Caster Wheels 32.8 inches
(83.3 cm)
32.8 inches
(83.3 cm)
Wheel Base: (Center of Caster Tire to
Center of Drive Tire)
48 inch Deck 52 inch Deck
48.0 inches (121.9 cm) 48.0 inches (121.9 cm)
Curb Weight:
48 inch Deck 52 inch Deck
20HP Kawasaki
Units
1081 lb (490 kg) 1115 lb (506 kg)
Accessory Weight Table Worksheet:
Use the table below to determine if extra weight
is required for the unit. Identify the accessories
and correct deck size and place the corresponding
values in the Accessory Score column. If the Total
Accessory Score meets the following, add the
recommended weight kit.
48 inch
Deck
52 inch
Deck
Accessory
Score
Light Kit
2 2
Michigan
Seat/CRSS
11
10
Bagger
0 0
Mulch Kit
-3 -3
Striper Kit -3 0
OCD02 -6 -6
Hitch Kit
1 1
Sunshade Kit
2
3
Total Accessory Score
Total Accessory Score Required Weight Kit(s)
0 – 9
None required
10 – 19
116-1173 Under toe board
mount weight kit
20 and Higher Two 116-1173 Under toe
board mount weight kits
or one 116-1173 Under toe
board mount weight kit
and one 116-1238 Front
toe board mount weight kit
Torque Requirements
Bolt Location
Torque
Blade Drive Sheave
Mounting Nut
140-145 ft-lb (190-197
N-m)
Blade Mounting Bolt
(lubricate with anti-seize)
55-60 ft-lb (75-81 N-m)
