Maintenance
Figure 40
1. Spring disc washers
Cleaning
Clean Engine and Exhaust
System Area
Service Interval: Before each use or daily
(May be required more
often in dry or dirty
conditions.)
CAUTION
Excessive debris around engine cooling air
intake and exhaust system area can cause engine,
exhaust area, and hydraulic system to overheat
which can create a re hazard.
Clean all debris from engine and exhaust system
area.
1. Stop engine, wait for all moving parts to stop, and
remove key. Engage parking brake.
2. Clean all debris from rotating engine air intake
screen, around engine shrouding, and exhaust
system area.
3. Wipe up any excessive grease or oil around the
engine and exhaust system area.
Remove Engine Shrouds and
Clean Cooling Fins
Service Interval: Every 100 hours
1. Stop engine, wait for all moving parts to stop, and
remove key. Engage parking brake.
2. Remove cooling shrouds from engine and clean
cooling ns. Also clean dust, dirt and oil from
external surfaces of engine which can cause
inadequate cooling.
3. Make sure cooling shrouds are reinstalled.
Operating the engine without cooling shrouds will
cause engine damage due to overheating.
Clean Hydro Cooling Fins
Service Interval: Before each use or daily
Removing debris from the hydro cooling ns will
allow the hydro system to run cooler and improve the
life of the hydro system.
1. Stop engine, wait for all moving parts to stop, and
remove key. Engage parking brake.
45
