Specications
Tires & Wheels
Drive Front Caster
Pneumatic
(Air-Filled)
Semi-
Pneumatic
Quantity
2 2
Tread Kenda K500
Smooth
Size 18x 8.50–8 11 x 4.00-5
Ply Rating
4
Pressure
14 psi
(97 kPa)
Cutting Deck
• Cutting Width: 36 inches (91.4 cm)
• Discharge: Side
• Blade Size: (2 ea.): 18.00 inches (45.7 cm)
• Blade Spindles: Solid steel spindles with 1.00 inch
(25.4 mm) I.D. bearings.
• Deck Drive:
– Electric clutch mounted on engine shaft.
– Blades driven by one belt (w/self-tensioning
idlers).
• Deck: Full oating deck is attached to support
frame, removable for service. Deck design allows
for bagging, mulching or side discharge.
• Deck Depth: 5.0 inches (12.7 cm)
• Cutting Height Adjustment:
Adjusts from 1 inch (2.5 cm) to 5 inches (12.7 cm)
in 1/4 inch (6.4 mm) increments
• Mulching Kit: Optional
• Bagger: Optional
Dimensions
Overall Width:
Deector Up 39.1 inches (99.3 cm)
Deector Down 48.0 inches (121.9 cm)
Overall Length:
Platform Up 61.5 inches (156.2 cm)
Platform Down 74.0 inches (188.0 cm)
Overall Height:
51.5 inches (130.8 cm)
Tread Width: (Outside to Outside of
Tires, Widthwise)
37.6 inches (95.5 cm)
Curb Weight:
800 lb (363 kg)
Note: Weights will vary slightly depending on
engine.
Torque Requirements
Bolt Location
Torque
Cutter Housing Spindle
Nut
130-160 ft-lb
(176-217 N-m)
Blade Mounting Bolt
(lubricate with anti-seize)
50-60 ft-lb (68-81 N-m)
Engine Deck/Mower
Deck Support Mount
Bolts
30-35 ft-lb (41-47 N-m)
Engine Mounting Bolts
17-23 ft-lb (23-31 N-m)
Wheel Lug Nuts
90-95 ft-lb (122-129 N-m)
Wheel Hub Nuts 175-225 ft-lb
(237-305 N-m)
Wheel Motor Mounting
Bolts
67-83 ft-lb (91-113 N-m)
