PART NO. DESCRIPTIONREF NO. QTY.
72" Mower Deck - Housing, Covers, Spindles & Blades - Rear Discharge
Footnotes
1 5300068 1 ASSM, MOWER DECK 72 RD (Includes safety decals.)
2 5061213B 1 SPINDLE COVER - RH
3 5061214B 1 SPINDLE COVER - LH
4 5022308 6 BODY CLIP, 5/16-18
5 5025155 6 WASHER, 5/16" SAE
6 5025011X6 6 BOLT, 5/16-18 x 3/4
7 5025394 18 NUT, 3/8-16 Hex Nylock Flange
8 5049438 3 SPINDLE ASSEMBLY, Complete
9 5025390X10 18 BOLT, Flange Head, 3/8-16 x 1-1/4
10 5022476 3 MOWER BLADE, 25"
11 5023273 3 MOWER BLADE, SAND, 25" (Applies to CE model only)
12 5025159 3 WASHER, 5/8" USS
13 5025320X14 3 BOLT, 5/8-11 x 1-3/4
14 5023156 12 BOLT, Flange Head, 5/16-18 x 1-1/4 (Applies to CE model only)
15 5047408 8 SPACER, .39 x .75 x .50 (Applies to CE model only)
16 5025392 12 NUT, 5/16-18 Hex Nylock Flange (Applies to CE model only)
17 5061409B 1 BLOWOUT BAFFLE - LH (Applies to CE model only)
18 5061413B 1 BAFFLE REINFORCEMENT (Applies to CE model only)
19 5061408B 1 BLOWOUT BAFFLE - RH (Applies to CE model only)
The above parts group applies to the following Mfg. Nos.:
2007
77
© Copyright Briggs and Stratton. All Rights Reserved.
5900204
(
S/N: 1210 & above
)
(
5000/72R
)
5900205
(
S/N: 1210 & above
)
(
5000/72RC
TP 400-7168-11-5Z-F
