PART NO. DESCRIPTIONREF NO. QTY.
Rear Suspension Group
Footnotes
1 5025298 2 SET SCREW, Square Head, 1/2-13 x 3
2 5025301 2 NUT, 1/2-13 Hex Jam
3 5025056 12 NUT, 1/2-13 Hex Nylon Lock
4 5025394 4 NUT, 3/8-16 Hex Nylock Flange
5 5043815 2 SPACER, .39 x 1.00 x .75
6 5025165 8 WASHER, 3/8" Fender
7 5025013X22 2 BOLT, 3/8-16 x 2-3/4
8 5022912 2 DAMPENER
9 5025013X16 2 BOLT, 3/8-16 x 2
10 5045904 2 SPRING COMPRESSION PLATE
11 5045898 2 SPRING RETAINER
12 5061181 2 SPRING, Compression
13 5045601B 1 SPRING SADDLE-LH
14 5045602B 1 SPRING SADDLE-RH (Not Shown)
15 5045588B 2 WHEEL MOTOR MOUNT
16 5025018X24 4 BOLT, 1/2-20 x 3
17 5025018X20 4 BOLT, 1/2-20 x 2-1/2
18 5046059B 2 SPACER PLATE
19 5025017X52 2 BOLT, 1/2-13 x 6-1/2
20 5025017X60 2 BOLT, 1/2-13 x 7-1/2
21 5025098 8 NUT, 1/2-20 Hex Nylon Lock
22 5061178 4 CAST A-ARM
23 5025294 8 BOLT, Allen Head, 1/2-13 x 3
The above parts group applies to the following Mfg. Nos.:
2007
43
© Copyright Briggs and Stratton. All Rights Reserved.
5901074
(
S/N: 1226 & above
)
(
IS5000Z/C3
5901071
(
S/N: 1226 & above
)
(
IS5000Z/C3
5901070
(
S/N: 1226 & above
)
(
IS5000Z/C3
TP 400-7168-11-5Z-F
