PART NO. DESCRIPTIONREF NO. QTY.
Parking Brake Group - Lower
Footnotes
1 5025013X18 2 BOLT, 3/8-16 x 2-1/4
2 5025156 6 WASHER, 3/8" SAE
3 5047125 2 SPACER, .39 x 1.00 x .88
4 5041930 2 SPACER, .38 x .50 x .27
5 5025096 2 NUT, 3/8-16 Hex Nylon Lock
6 5025045 2 NUT, 5/16-24, Hex Nylon Lock
7 5025155 2 WASHER, 5/16" SAE
8 5022361 2 SPRING, Compression
9 5047382B 2 LINK, Brake Lock
10 5023324 2 CABLE, Brake
11 5049388B 1 BRACKET, Cable Mount-LH
12 5049389B 1 BRACKET, Cable Mount-RH (Not Shown)
13 5023320 2 SPRING, Compression
14 5025164 2 WASHER, 5/16" Fender
15 5025033 2 NUT, 5/16-24 Hex
16 5025213X8 2 CLEVIS PIN, 5/16 x 1
17 5023323 2 CLEVIS, Steel, 5/16-24
18 5025203X10 2 COTTER PIN, 1/8" X 1-1/4"
19 25400 4 SHOULDER BOLT, 1/2" x 2-3/4"
20 5023300 2 BRAKE HUB
21 5023299 2 BRAKE CALIPER
22 5049391A 2 BRAKE CALIPER MOUNT
23 5025128 4 NUT, 3/8-16 Hex Serrated Flange
The above parts group applies to the following Mfg. Nos.:
2007
39
© Copyright Briggs and Stratton. All Rights Reserved.
5901074
(
S/N: 1226 & above
)
(
IS5000Z/C3
5901071
(
S/N: 1226 & above
)
(
IS5000Z/C3
5901070
(
S/N: 1226 & above
)
(
IS5000Z/C3
TP 400-7168-11-5Z-F
