PART NO. DESCRIPTIONREF NO. QTY.
PTO Clutch & Anchor Group
Footnotes
1 5025011X8 5 BOLT, 5/16-18 x 1
2 5047563B 1 CLUTCH ANCHOR
3 5021030 1 TIE WRAP, 5-1/2"
4 5025127 2 NUT, 5/16-18 Hex Small Serrated Flange
5 5025045 3 NUT, 5/16-24, Hex Nylon Lock
6 5025155 2 WASHER, 5/16" SAE
7 5044617 3 WASHER, Clutch Anchor
8 5043636 1 CLUTCH ANCHOR PAD
9 5050407X2 1 KEY, 1/4 SQ. X 3
10 5022575 1 BELT, Clutch Drive (set of 2)
11 5045473 1 CRANKSHAFT BOLT, 7/16 x 1-1/2
12 5045475 1 SPACER, .45 x 1.88 x .38
13 5022884 1 PTO CLUTCH
14 5025013X24 1 BOLT, 3/8-16 x 3
15 5025156 4 WASHER, 3/8" SAE
16 5022797 1 PULLEY, Idler
17 5025128 2 NUT, 3/8-16 Hex Serrated Flange
18 1608395 1 SPRING, Extension
19 5025100 1 NUT, 3/8-16 Hex Side Lock
20 5046916 1 SPACER, .51 x 1.75 x .75
21 5022250 2 BUSHING, Flange
22 5020095 1 GREASE FITTING
23 5046565B 1 CLUTCH DRIVE IDLER ARM
24 5045305 1 PIVOT SLEEVE, Long
25 5025158 1 WASHER, 1/2" SAE
26 5025056 1 NUT, 1/2-13 Hex Nylon Lock
27 5025321 1 SCREW HOOK, 3/8-16 x 4-1/4
28 5025096 1 NUT, 3/8-16 Hex Nylon Lock
The above parts group applies to the following Mfg. Nos.:
2007
27
© Copyright Briggs and Stratton. All Rights Reserved.
5901074
(
S/N: 1226 & above
)
(
IS5000Z/C3
5901071
(
S/N: 1226 & above
)
(
IS5000Z/C3
5901070
(
S/N: 1226 & above
)
(
IS5000Z/C3
TP 400-7168-11-5Z-F
