22

2. Projecting an Image (Basic Operation)

 Correcting Keystone Distortion Manually

Ifthescreenistiltedvertically,keystonedistortionbecomeslarge.Tocorrectkeystonedistortionmanually,proceed

withthefollowingstepstocorrectkeystonedistortion.

NOTE:

• Themaximumrangeofverticalkeystonecorrectionis+/−30degrees.

• TheKeystonecorrectioncancauseanimagetobeslightlyblurredbecausethecorrectionismadeelectronically.

• TheKeystonecorrectionrangecanbemadenarrower,dependingonasignaloritsaspectratioselection.

Adjusting with buttons on the cabinet

1. Pressthe or buttonwithnomenusdisplayed.

 Thekeystonebarwillbedisplayed.

2. Usethe or tocorrectthekeystonedistortion.

3. PresstheENTERbutton.

 Thekeystonebarwillbeclosed.

NOTE:

• Whenthemenuisdisplayed,theaboveoperationisnotavailable.Whenthemenuisdisplayed,presstheMENUbuttontoclose

themenuandstarttheKeystonecorrection.

 Fromthemenu,select[SETUP]→[GENERAL]→[KEYSTONE].Thechangescanbesavedwith[KEYSTONESAVE].(→page

91)

• KeystonecontrolisnotavailablewiththeorbuttonwhenVIEWERorNETWORKisused.
