RevisionCommentsPart DescriptionPart No.Ref.
Drawing Image Numberdwg24610
HUB GREASE CAP200-001D1.
WLDMT. CENTER AXLE318-571H2.
WLDMT. TANDEM ARM318-573H3.
GREASE ZERK 1/4-28 THD FORMING800-080C4.
HHCS 1/2-13X3 1/4 GR5802-099C5.
S/N 543468+HHCS 1-8X9 GR8 PLT802-783C6.
S/N 543467-HHCS 1-8X9 GR5802-110C6.
HUB STUD 1/2-20X1.88 GR5802-779C7.
S/N 543468+HHCS 1-8X6 GR8802-854C8.
S/N 543467-HHCS 1-8X5 1/2 GR5802-205C8.
NUT LOCK 1/2-13 PLT803-019C9.
NUT HEX SLOTTED 3/4-16803-053C10.
NUT HEX 1/2-20 X 5/8 HIGH803-310C11.
WASHER FLAT 1 SAE804-029C12.
WASHER HARDENED .81ID804-216C13.
PIN COTTER 5/32 X 1 3/4 LG805-246C14.
TIRE & WHL LAM. 6X9X21(5-BOLT)814-265C15.
AC TIRE FF 24X7.7 2PC 5-BOLT814-288C16.
AC TIRE 24 X 7.7 2PC. 5-BOLT814-285C17.
TIRE 24X7.7-14 (814-263C)814-266C18.
RIM 2PC. 4BLT 10X6 BLACK814-267C19.
TUBE FOR 24X7.7-14 (814-263C)814-268C20.
SPINDLE-SINGLE BOLT-ON815-241C21.
HUB 5-BOLT W/CUPS/STUDS815-243C22.
SEAL 1.75ID CR17617816-497C23.
BEARING CONE LM-48548822-034C24.
BEARING CUP LM-48510822-033C25.
S/N 543467-SPACER 1 5/8ODX1IDX1 1/4827-070C26.
BUSHING CYL 1 1/4 X 1 X 1890-005C27.
BUSHING 1.25ODX1.00IDX3.00890-766C28.
S/N 563872- Replace W/ 2 ea.
890-005C
BUSHING 1.25ODX1.00IDX3.75890-817C29.
BEARING CONE LM-67048822-021C30.
BEARING CUP LM-67010822-020C31.
NUT HEX SLOTTED 1-8 PLT.803-071C32.
HHCS 1/2-13X2 GR5802-128C33.
WASHER FLAT 1/2 SAE PLT804-016C34.
NUT HEX FLG. LOCK 1/2-13 PLT.803-169C35.
WLDMNT PIVOT PIN TANDEM AXLE330-004H36.
PIN COTTER 3/16 X 2805-058C37.
S/N 543468+NUT HEX TOP LOCK 1-8 PLT803-168C38.
S/N 543467-NUT HEX FLG LOCK 1-8 GR B PLT803-258C38.
S/N 563873+BUSHING CYL 1 1/4 X 1 X 1890-005C39.
09/02/08 RC5515, RCM5515, RC6515 & RCM6515 Rotary Cutters 318-721P 61
Table of Contents Part Number Index
Section 3: Axles Land Pride
Axle Tandem Center Deck
Applies to RC5515, RC6515, RCM5515, RCM6515
