RevisionCommentsPart DescriptionPart No.Ref.
Drawing Image Numberdwg24553
SHAFT WELDMENT318-358H1.
HITCH TOP PLATE318-691D2.
FORMED HITCH SUPPORT318-693D3.
WLDMT. SWIVEL TONGUE318-694H4.
ASSY. BAR TITE HITCH318-833S5.
WELDMENT HITCH CLEVIS318-834H6.
WELDMENT HITCH BASE318-835H7.
GREASE ZERK STRAIGHT 1/4-28800-001C8.
GREASE ZERK 1/4-28 THD FORMING800-080C9.
HHCS 1-8X6 1/2 GR5802-074C10.
HHCS 1-8X2 1/2 GR5802-096C11.
HHCS 1-8X5 GR5802-235C12.
HHCS 3/4-10X5 1/2 GR5802-594C13.
NUT HEX TOP LOCK 1-8 PLT803-168C14.
NUT HEX FLANGE LOCK 3/4-10 PLT803-181C15.
NUT HEX SLOTTED 1 1/2-6 PLT803-301C16.
WASHER FLAT 1 USS PLT804-028C18.
WASHER FLAT 3/4 SAE PLT804-024C17.
WASHER FLAT 1 3/8HARD ASTMF436804-171C19.
PIN COTTER 1/4 X 2 1/2 PLT805-105C20.
SAFETY CHAIN 10000 LB890-182C21.
SIDEWIND JACK 5000 LB890-226C22.
BUSHING 1.25ODX1.00IDX3.00890-766C23.
BUSHING 1.50ODX1.00IDX1.25890-862C24.
09/02/08 RC5515, RCM5515, RC6515 & RCM6515 Rotary Cutters 318-721P 47
Table of Contents Part Number Index
Section 2: Decks & Hitchs (RC65) Land Pride
Hitch Bar Tite
Applies to RC6515, RCM6515
