RevisionCommentsPart DescriptionPart No.Ref.
Drawing Image Numberdwg24542
CO NUT, CASTLE M30 X 28.2.2.005551.
CO BLANK WASHER0.288.7101.002.
FORMED HINGE BRACKET318-322D3.
SHIELD BRACKET WELDMENT318-401H4.
WLDMT. SPRING SHOCK318-606H5.
WLDMT. SKID SHOE318-628H6.
DECK, SMOOTH CENTER WO/DR318-758H7.
DECK, CENTER WO/DR GREEN318-758H817.
DECK, CENTER WO/DR ORANGE318-758H827.
DECK, CENTER WO/DR RED318-758H837.
DECK, SMOOTH CENTER W/DR318-804H7.
DECK, CENTER W/DR GREEN318-804H817.
DECK, CENTER WO/DR ORANGE318-804H827.
DECK, CENTER W/DR RED318-804H837.
HHCS 1/4-20X1 GR5802-005C8.
HHCS 3/8-16X1 GR5802-017C9.
Comer GearboxHHCS 5/8-11X2 1/2 GR5802-058C10.
HHCS 3/4-10X2 1/4 GR5802-065C11.
HHCS 5/8-11X4 1/2 GR5802-100C12.
HHCS M8X1.25X20 GR8.8802-314C13.
HHCS 1-8X3 GR5802-368C14.
HHCS 3/4-10X8 GR5 PLT802-469C15.
NUT LOCK 3/8-16 PLT803-013C16.
NUT LOCK 3/4-10 PLT803-026C17.
NUT HEX TOP LOCK 1-8 PLT803-168C18.
NUT HEX NYLOCK 1/4-20803-255C19.
S/N 584787+ to Mount Plate Item #45NUT HEX FLANGE LOCK 5/8-11 PLT803-263C20.
Comer GearboxNUT HEX TOP LOCK 5/8-11 PLT803-271C21.
WASHER FLAT 1/4 SAE PLT804-007C22.
WASHER LOCK SPRING 5/16 PLT804-009C23.
WASHER FLAT 5/16 USS PLT804-010C24.
WASHER FLAT 3/8 SAE PLT804-012C25.
WASHER FLAT 3/4 USS PLT804-024C26.
PIN COTTER 5/32 X 1 1/4 LG805-045C27.
PIN COTTER 1/4 X 2 1/2 PLT805-105C28.
PIN CLEVIS 3/8 X 5 1/2 PLT805-309C29.
SPRING HOSE LOOP807-023C30.
SPRING COMP 1.88OD x .362W807-143C31.
MANUAL STORAGE CONTAINER816-481C32.
KNOB 3/8-16 FEMALE THD 2 3/8OD817-259C33.
PLASTIC DIVIDER BOX SHIELD817-416C34.
RC5515GBOX RC50 1:1.46 CCW826-315C35.
GBOX RC50 1:1.46 CCW GREEN826-315C8135.
GBOX RC50 1:1.46 CCW ORANGE826-315C8235.
GBOX RC50 1:1.46 CCW RED826-315C8335.
RC6515GBOX RC60 1:1.46 CCW826-320C35.
GBOX RC60 1:1.46 CCW GREEN826-320C8135.
GBOX RC60 1:1.46 CCW ORANGE826-320C8235.
GBOX RC60 1:1.46 CCW RED826-320C8335.
RCM5515GBOX RCM50 1.21:1 CCW826-318C35.
GBOX RCM50 1.21:1 CCW GREEN826-318C8135.
GBOX RCM50 1.21:1 CCW ORANGE826-318C8235.
GBOX RCM50 1.21:1 CCW RED826-318C8335.
RCM6515GBOX RCM60 1.21:1 CCW826-323C35.
GBOX RCM60 1.21:1 CCW GREEN826-323C8135.
GBOX RCM60 1.21:1 CCW ORANGE826-323C8235.
GBOX RCM60 1.21:1 CCW RED826-323C8335.
09/02/08 RC5515, RCM5515, RC6515 & RCM6515 Rotary Cutters 318-721P 37
Table of Contents Part Number Index
Section 2: Decks & Hitchs (RC65) Land Pride
Deck Center Section
Applies to RC6515, RCM6515
