RevisionCommentsPart DescriptionPart No.Ref.
Drawing Image Numberdwg16609
ROUND ROD 1/4 X 28 1/2318-106D1.
CHAIN WELD 5/16 PROOF X 7-LINK890-393C2.
NUT HEX WHIZ 1/2-13 PLT803-037C3.
RHSNB 1/2-13X1 1/4 GR5802-214C4.
CG. WING FRONT INNER318-099D5.
ROUND ROD 1/4 X 49318-109D6.
Includes items 1 through 4 & 10ASSY. CG. FRT. WING OUTER RH.318-060K7.
Rev. 2 not compat. w/Rev. 1(S/N 292792+) Includes items 2
through 6
ASSY. CG. FRT. WING INNER RH318-171K8.
Rev. 1(S/N 292791-)ASSY. CG. FRT. WING INNER318-059K8.
ROUND ROD 1/4 X 31 1/2318-107D9.
CG. WING FRONT OUTER RH.318-101D10.
Includes items 4, 9, 12, 13 & 29ASSY. CG. REAR WING318-064K11.
CG. WING REAR318-104D12.
RHSNB 1/2-13X1 1/2 GR5802-106C13.
Includes items 16, 17, & 21 through
24
ASSY. FRT. WING OUT. RH. DEF.318-092K14.
Rev. 2 not compat. w/Rev. 1(S/N 292792+) Includes items 16
through 20
ASSY. FRT. WG. INNER DEF. RH.318-175K15.
Rev. 1(S/N 292791-)ASSY. FRT. WING INNER DEF.318-091K15.
RHSNB 3/8-16X1 1/4 GR5802-155C16.
NUT HEX WHIZ 3/8-16 PLT803-198C17.
RUBBER GUARD FLAT BRKT. 47 1/4318-130D18.
Rev. 2 not compat. w/Rev. 1(S/N 292792+)FRT. DEF. BRKT. WING INNER RH.318-185D19.
Rev. 1(S/N 292791-)FRT. DEF. BRKT. WING INNER318-135D19.
RUBBER GUARD FRT. WING INNER816-249C20.
RUBBER GUARD FLAT BRKT. 12 1/2318-140D21.
RUBBER GUARD FLAT BRKT. 8318-131D22.
RUBBER GUARD FRT. WING OUTER816-250C23.
FRT. DEF. BRKT. WING OUTER RH.318-136D24.
Includes items 16, 17, 26, 27 & 28ASSY. REAR WING DEFLECTOR318-096K25.
RUBBER GUARD FLAT BRKT. 28 1/2318-129D26.
RUBBER GUARD REAR WING816-246C27.
RUBBER GUARD WING REAR BRKT.318-128D28.
CHAIN WELD 5/16 PROOF X 5 LINK890-341C29.
Includes items 2, 3, 4, 35 & 38ASSY. DBL.CG.FRT.WING OUT.RH.318-068K30.
Includes items 4, 13, 29, 33 & 34ASSY. CG. REAR WING318-072K31.
Rev. 2 not compat. w/Rev. 1(S/N 292792+)Includes items 2,3,4,
36 & 37
ASSY. DBL.CG.FRT.WING INNER RH318-172K32.
Rev. 1(S/N 292791-)ASSY. DBL. CG. FRT. WING INNER318-067K32.
ROUND ROD 1/4 X 31 1/2318-107D33.
CG. WING REAR DUAL318-123D34.
CG. FRONT WING OUTER RH. DUAL318-119D35.
ROUND ROD 1/4 X 49318-109D36.
CG. FRONT WING INNER DUAL318-118D37.
ROUND ROD 1/4 X 28 1/2318-106D38.
02/03/09 RC5010, RCM5010, RC6010 & RCM6010 Rotary Cutters 318-622P 57
Table of Contents Part Number Index
Section 5: Guards Land Pride
RC5010 & RC6010 SERIES (540 RPM)
Guards Right Hand Deck (S/N 292791-)
Applies to RC5010, RC6010
