RevisionCommentsPart DescriptionPart No.Ref.
Drawing Image Numberdwg22163
ROUND ROD 1/4 X 73318-336D1.
CHAIN WELD 5/16 PROOF X 7-LINK890-393C2.
NUT HEX WHIZ 1/2-13 PLT803-037C3.
RHSNB 1/2-13X1 1/4 GR5802-214C4.
Includes items 1, 2, 4, 5 & 9ASSY. SGL. CG. FRT. WING RH.318-322K5.
ROUND ROD 1/4 X 31 1/2318-107D6.
RC5015 WING CHAINGUARD RH318-328D7.
Includes items 4, 8, 11, 12 & 22ASSY. CG. REAR WING318-064K8.
CG. WING REAR318-104D9.
RHSNB 1/2-13X1 1/2 GR5802-106C10.
Includes items 14 through 16ASSY. FRT. WING RH. DEF.318-337K11.
RHSNB 3/8-16X1 1/4 GR5802-155C12.
NUT HEX WHIZ 3/8-16 PLT803-198C13.
FRT. DEF. WING BRKT.318-359D14.
FRONT DEFLECTOR WING816-351C15.
Includes items 14, 15, 19, 20 & 21ASSY. REAR WING DEFLECTOR318-096K16.
RUBBER GUARD FLAT BRKT. 28 1/2318-129D17.
RUBBER GUARD REAR WING816-246C18.
RUBBER GUARD WING REAR BRKT.318-128D19.
CHAIN WELD 5/16 PROOF X 5 LINK890-341C20.
Includes items 1, 2, 4, 5, & 27ASSY. DBL. CG. FRT. WING RH.318-327K21.
Includes items 4, 12, 22, 25 & 26ASSY. CG. REAR WING318-072K22.
ROUND ROD 1/4 X 31 1/2318-107D23.
CG. WING REAR DUAL318-123D24.
RC5015 WING FRONT DBLCHAIN RH318-342D25.
02/03/09 RC5010, RCM5010, RC6010 & RCM6010 Rotary Cutters 318-622P 199
Table of Contents Part Number Index
Section 5: Guards Land Pride
RCM5010 & RCM6010 SERIES (1000 RPM)
Guards Right Hand Deck (S/N 292792+)
Applies to RCM5010, RCM6010
