RevisionCommentsPart DescriptionPart No.Ref.
Drawing Image Numberdwg16924
WLDMT. SKID SHOE LH.318-146H1.
NUT HEX WHIZ 1/2-13 PLT803-037C2.
HFS 1/2-13X2 GR8802-456C3.
OMNI Gear BoxWASHER LOCK SPRING 3/4 PLT804-023C4.
OMNI Gear BoxHHCS 3/4-10X1 1/2 GR5802-184C5.
WLDMT. SKID SHOE RH.318-145H6.
DIVBX.RCD101HD 1 3/4-20 1:1.21826-179C7.
DIVBX.RCD101HD 1 3/4-20 1:1.21 GREEN826-179C817.
DIVBX.RCD101HD 1 3/4-20 1:1.21 RED826-179C837.
Metal (S/N 325491-)SHIELD DIVIDER BOX318-114D8.
Plastic (S/N 325492+)PLASTIC DIVIDER BOX SHIELD817-416C8.
WASHER LOCK SPRING 1/2 PLT804-015C9.
HHCS 1/2-13X3/4 GR5802-032C10.
Metal (S/N 325491-)WLDMT. GEARBOX SHIELD318-099H11.
WASHER LOCK SPRING 3/8 PLT804-013C12.
NUT WING 3/8-16 PLT803-231C13.
WASHER FLAT 3/8 SAE PLT804-012C14.
(S/N 325491-)WLDMT. SHIELD BRACKET318-098H15.
(S/N 325492+)SHIELD BRACKET WELDMENT318-401H15.
WASHER FLAT 5/16 USS PLT804-010C16.
WASHER LOCK SPRING 5/16 PLT804-009C17.
OMNI GEARBOXHHCS 5/16-18X3/4 GR5802-007C18.
COMER GEARBOXHHCS M8X1.25X20 GR8.8802-314C18.
RC5015PTO INT. CAT.4 540W/CLUTCH826-183C19.
Rev. 2RC6015 (S/N 461935 to 461937,
468573+)
PTO E60 X 21.7 1280NM CLUTCH826-478C19.
Rev. 1RC6015 (S/N 461934-)PTO INT. W2500/WSC CAT5 540826-260C19.
SPRING HOSE LOOP807-023C20.
RC5015 (S/N 325492+)GBOX RC50 1.75-20 1:1.46 CCW826-315C21.
GBOX RC50 1.75-20 1:1.46 CCW826-315C8121.
GBOX RC50 1.75-20 1:1.46 CCW826-315C8321.
RC6015 (S/N 325492+)GBOX RC60 1.75-20 1:1.46 CCW826-320C21.
GBOX RC60 1.75-20 1:1.46 CCW GREEN826-320C8121.
GBOX RC60 1.75-20 1:1.46 CCW RED826-320C8322.
RC5015 (S/N 325491-)GBOX RC130S 1.75-20 1:1.46 CW826-174C21.
RC6015 (S/N 325491-)GBOX RC130L 1.75-20 1:1.46 CW826-231C21.
HHCS 3/4-10X2 GR5802-064C22.
WLDMT. CYLINDER SPRING BASE318-169H23.
SPRING COMP 1.88OD x .362W807-143C24.
HHCS 1-8X5 GR5802-235C25.
NUT HEX TOP LOCK 1-8 PLT803-168C26.
BLADE BOLT ACCESS COVER312-812D27.
BLADE BOLT ACCESS COVER GREEN312-812D8127.
BLADE BOLT ACCESS COVER RED312-812D8327.
NUT HEX FLG TOP LK 3/4-10 PLT803-299C28.
RC5015 (S/N 325491-)WLDMT. CENTER SECTION318-170H29.
RC5015 (S/N 325492 to 419601-)WLDMT. CENTER SECTION318-374H29.
RC5015 (S/N 419602+)WLDMT. CENTER SECTION318-692H29.
WLDMT. CENTER SECTION GREEN318-692H8129.
WLDMT. CENTER SECTION RED318-692H8329.
RC5015WLD. CTR. SECTION W/DECK RINGS318-885H29.
WLD. CTR. SECTION W/DECK RINGS GREEN318-885H8129.
WLD. CTR. SECTION W/DECK RINGS RED318-885H8329.
RC6015 (S/N 325491-)WLDMT. CENTER SECTION318-149H29.
RC6015 (S/N 325492 to 419601-)WLDMT. CENTER SECTION318-375H29.
RC6015 (S/N 419602+)WLDMT. CENTER SECTION318-568H29.
WLDMT. CENTER SECTION GREEN318-568H8129.
02/03/09 RC5010, RCM5010, RC6010 & RCM6010 Rotary Cutters 318-622P 15
Table of Contents Part Number Index
Section 3: Decks Land Pride
RC5010 & RC6010 SERIES (540 RPM)
Deck Center Section (540 RPM) (S/N 217474+)
Applies to RC5010, RC6010
