Specications
• Armrests: Standard–foam padded ip-up
adjustable height armrests.
• Seat Safety Switch: Incorporated into the Safety
Interlock System.
Hydrostatic Ground Drive System
• Hydrostatic Pumps: Two Hydro Gear ZT2800
Integrated drive systems.
• Hydraulic Oil Type: Use Mobil 1 15W-50
Synthetic motor oil.
• Speeds:
– 0-7.0 mph (11.3 km/hr) forward.
– 0-5.0 mph (8.0 km/hr) reverse.
• Drive wheel releases, located on left and right
sides of engine deck, allow machine to be moved
when the engine is not running and brake is off.
Tires & Wheels
Drive
Front
Caster
Pneumatic (Air-Filled)
Pneumatic
(Air-Filled)
Deck Size
48 52
All Decks
Quantity
2 2 2
Tread
Turf Tec Turf Tec Smooth
Size 20 x 8.00-8 20 x 10.00-8 10 x 4
Ply Rating
4 4
Pressure
13 psi
(90 kPa)
13 psi
(90 kPa)
13 psi
(90 kPa)
Cutting Deck
• Cutting Width:
– 48 inch Deck: 48 inches (122 cm)
– 52 inch Deck: 52 inches (132 cm)
• Discharge: Side
• Blade Size: (3 ea.)
– 48 inch Deck: 16.25 inches (41.3 cm)
– 52 inch Deck: 18.00 inches (45.7 cm)
• Blade Spindles: Solid steel spindles with no
maintenance bearings.
• Deck Drive: Electric clutch mounted on vertical
engine shaft. Blades are driven by one belt
(w/self-tensioning idler) direct from the engine.
• Deck: Full oating deck is attached to out-front
support frame. Maximum turf protection is
provided with three anti-scalp rollers (both deck
sizes).
Deck design allows for bagging, mulching or side
discharge.
• Deck Depth:
– 48 inch Deck: 5.0 inches (12.7 cm)
– 52 inch Deck: 5.0 inches (12.7 cm)
• Cutting Height Adjustment: A foot deck lift lever
is used to adjust the cutting height from 1 1/2
inch (3.8 cm) to 4 1/2 inches (11.4 cm) in 1/2
inch (1.3 cm) increments.
• Mulching Kit: Optional.
Dimensions
Overall Width:
48 inch Deck 52 inch Deck
Without Deck 45.5 inches
(116 cm)
47.0 inches
(119 cm)
Deector Up 48.3 inches
(122 cm)
53.0 inches
(135 cm)
Deector Down 59.4 inches
(151 cm)
64.2 inches
(163 cm)
Overall Length:
48 inch Deck 52 inch Deck
73.4 inches (186 cm) 73.4 inches (186 cm)
Overall Height:
48 inch Deck 52 inch Deck
41.8 inches (106 cm) 41.8 inches (106 cm)
14
