ENGINE GROUP
- 17 -
Item
Part No.
Description
Qty.
1 103-3078-03 Strap, Engine Guard ..............................2
2 32128-20 Nut, Whizlock 5/16-18............................20
3 322-3 Screw, 5/16-18x3/4................................2
4 33114-025 Screw, HH M8-1.25 x 20 (KAW).............1
3212-10 Screw, HH 7/16-20 x 2 1/2 (KOH) ..........1
5 1-653313 Gasket, (23 HP KAW)............................2
1-653290 Gasket, (19 HP KAW)............................2
6 103-3426 Muffler, Kit (KOH)...................................1
7 1-805005 Washer, Lock 5/16 Heavy (KOH)...........1
8 3256-3 Washer, 5/16 Std Flat............................2
9 3296-29 Nut, Nyloc 5/16-18 (KAW)......................4
32128-20 Nut, Whizlock 5/16-18 (KOH).................4
10 322-10 Screw, HH 5/16-18 x 2...........................4
11 103-3218-03 Wld, Tailpipe Guard...............................1
12 109-0876 Asm, Oil Drain W/Plug (KOH)................1
13 109-8385-03 Anchor, Clutch (KOH) ............................1
109-7070-03 Anchor, Clutch (KAW)............................1
14 103-3219-03 Guard, Rear LHP...................................1
15 1-805004 Washer, Lock 1/4 Hvy (KOH).................4
1-805004 Washer, Lock 1/4 Hvy (KAW)................3
16 32128-33 Nut, Flange 1/4-20 (KOH) ......................6
32128-33 Nut, Flange 1/4-20 (KAW)......................4
17 3229-10 Screw, Carr 1/4-20 x 1/2 (KOH) .............6
3229-10 Screw, Carr 1/4-20 x 1/2 (KAW).............4
18 103-3288-03 Guard, Muffler RH (56”) .........................1
19 103-3287-03 Guard, Muffler LH (56”)..........................1
20 1-807259 Key ........................................................1
21 103-9891 Spacer, Crankshaft (27 KOH) ................1
103-2308 Spacer, Crankshaft (KAW & 23 KOH)....1
22 33113-020 Screw, HH M6-1 x 20mm (KOH)............2
23 33013-00 Nut, Hex M6-1 (KOH).............................2
24 1-603610 Washer, Disc Spring 7/16......................2
Item
Part No.
Description
Qty.
25X 3212-12 Screw, 7/16-20 x 3 (KAW).....................1
X
3212-10 Screw, 7/16-20 x 2 1/2 (KOH)................ 1
26 1-303335 Plastic Tie (Large)................................. 1
27 1-303334 Washer, Spring Disc.............................. 4
28 3256-23 Washer, 5/16 SAE Flat(46”&50”)........... 4
3256-23 Washer, 5/16 SAE Flat (56”) ................. 12
29 103-2740-03 Shield, Heat........................................... 1
30 33113-016 Screw, HH M6-1 x 16mm (KAW)........... 2
31 33113-025 Screw, HH M6-1 x 25mm (KAW)........... 1
32 107-8421-03 Counterweight, 60# (56”)...................... 1
33 322-7 Screw, Cap HH 5/16-18x1 1/2 (56”)....... 8
34
109-4490 Asm, Hose Oil Drain W/Plug (KAW)...... 1
35 109-1012 Plug....................................................... 1
36 103-3427 Muffler, Kit 23HP (KAW)........................ 1
103-4483 Muffler, Kit 19HP (KAW)........................ 1
37 103-2993-03 Bracket, Muffler LH (23 HP KAW) ......... 1
109-3476-03 Bracket, Muffler LH (19 HP KAW) ......... 1
38 103-2994-03 Bracket, Muffler RH (23 HP KAW)......... 1
109-3477-03 Bracket, Muffler RH (19 HP KAW)........ 1
39 1-653291 Gasket, (KOH)....................................... 2
40 103-3094-03 Deflector, Air LH (KOH)......................... 1
41 103-3095-03 Deflector, Air RH (KOH) ........................ 1
42 103-2987-03 Bracket, Muffler LH (KOH)..................... 1
43 103-2988-03 Bracket, Muffler RH (KOH)....................1
44 109-9276 Clutch, W/Pigtail (KAW & 23 KOH) ....... 1
109-9275 Clutch, W/Pigtail (27 KOH).................... 1
103-3012 Kit, Brake Pole Module.......................... 1
45 103-3913 Sheave, Pump Drive (KAW).................. 1
103-9772 Sheave, Pump Drive (KOH)................... 1
46 322-5 Screw, HH 5/16-18 x 1 (46 & 50)........... 17
322-5 Screw, HH 5/16-18 x 1 (56) ................... 9
Exmark black touch up spray paint – gloss black.
X Use a Teflon Pipe Sealant or equivalent on threads.
X Use Pro-Lock, Nut Type (P/N 1-840022, .5ml tube) on clutch bolt.
Kohler Replacement Parts List
(Refer to Engine Owner’s Manual)
Description
Kohler P/N
Air Filter Element – Outer.............2508301-S
Air Filter Element – Inner..............2508304-S
Oil Filter........................................12 050 01
Kawasaki Replacement Parts List
(Refer to Engine Owner’s Manual)
Description
Kawasaki P/N
23 HP Air Filter Element Kit (Inner & Outer)...........11010-7004
19 HP Air Filter Element ........................................11013-7028
