MAINFRAME GROUP
- 9 -
Item
Part No.
Description
Qty.
1O 103-3524 Seat, Complete W/Armrests.....................1
2 1-643255 Track, Seat (4” Adjust.) ............................1
103-8386 Spring, Seat Rail ......................................1
3 1-543401 Spacer, Seat Track...................................2
4 103-0292 Cushion, Armrest (RH).............................1
)
103-0291 Cushion, Armrest (LH)..............................1
5 103-3520 Cushion, Backrest ....................................1
6▬
103-2769 Wheel/Tire Assy (46” MultiTrac C/S) ........2
103-2770 Wheel/Tire Assy(50”&56” MultiTrac C/S)..2
►
1-653010 Wheel/Tire Assy (46” TurfMaster).............2
1-653158 Wheel (46” Deck) .....................................2
1-653161 Wheel (50” & 56”).....................................2
103-2771 Tire, 24 x 9.5-12 4 Ply (MultiTrac C/S)......2
1-653160 Tire, 23 x 9.5-12-4 Ply (TurfMaster)..........2
7 103-5961 Catch, Seat Latch.....................................1
8 323-39 Screw, 3/8-16 x 5......................................2
9 32128-20 Nut, Whizlock 5/16-18..............................16
10 3296-29 Nut, Nyloc 5/16-18....................................3
11 103-1731 Rod, Seat Hold Up ...................................1
12 322-5 Screw, 5/16-18 x 1....................................3
13
109-3970
Asm, Mainframe(109-3967-03)
W/Decals..................................................
1
14 32128-33 Nut, Nyloc 1/4-20......................................2
15 242-50 Nut, Wheel 1/2-20 ....................................8
16 3296-39 Nut, Nyloc 3/8-16......................................3
17
109-2164
Asm, Console(103-9843-03)
W/Decals..................................................
1
18
109-2165
Panel, Instrument (103-7939-03)
W/Decals..................................................
1
193 FRPSL Kit, Rops LHP...........................................1
20 322-3 Screw, 5/16 –18 x 3/4...............................3
Item
Part No.
Description
Qty.
21 103-3521 Cushion, Seat .........................................1
22 3256-23 Washer, Flat 5/16 SAE ............................2
23 103-4553 Asm, Rops Fold Pin .................................2
24 110-5850 Asm, Seat Frame.....................................1
25 3296-73 Nut, Nyloc 1/4-20 (black)..........................2
26 103-7935-03 Bracket, Instrument Panel........................1
27 322-4 Screw, HH 5/16-18 x 7/8 ..........................2
28 1-513658 Bumper ....................................................2
29 109-2365 Bumper, Rubber.......................................4
30 1-633859 Seat Frame..............................................1
31 322-2 Screw, 5/16-18 x 5/8 ................................6
32 1-633396 Clip, Loom................................................1
33 3256-3 Washer, Flat Std 5/16 ..............................4
34 103-8383 Bolt, Seat Cushion ...................................11
35 110-0883 Asm, Seat Belt.........................................1
36 3296-7 Nut, Nyloc 7/16-20 ...................................2
37 3231-22 Bolt, Carriage 3/8-16x1 ............................2
38 325-13 Screw, HH 1/2-13 x 3 1/4 .........................2
39 32128-23 Nut, Hex Flange Side Lock 1/2-13............2
40 107-3155 Cotter, Hair Pin Double Loop....................2
41 3212-4 Screw, HH 7/16-10 x 1 .............................2
42 323-6 Screw, HH 3/8-16 x 1...............................8
43 3290-357 Nut, Whizlock 3/8-16................................8
44 98-5975 Washer, Spring Disk 3/8 ..........................8
45 103-4434 Grip..........................................................1
46 110-5808 Latch, Seat...............................................1
47 107-0075 Bushing....................................................1
48 110-5831 Spring ......................................................1
49 323-20 Screw, 3/8-16 x 3 1/4 ...............................1
50 3256-24 Washer, 3/8 SAE Flat ..............................1
Exmark black touch up spray paint – gloss black.
) Not Illustrated.
Includes ROPS fold pin plus hairpin item #40.
3 Rollover protection frame is serviced as a complete assembly only. Includes complete ROPS frame, mounting
hardware, fold pivot and locking hardware, seat frame assembly item #24, catch item #7, and seat belt assembly
item #35.
O Includes armrests and seat back decal. Does not include seat belt or tracks.
▬ Standard on all models except LHP19KA465 S/N 739053 & Higher
► Standard on LHP19KA465 S/N 739053 & Higher
