16
(4) Fall the lighting arm (R) unit, and turn the camera head
to the position shown in the right figure (the position
with the camera head slightly turned to the rear side
panel).
Note: The lighting arm (L) cannot be independently
fallen.
Note: Be sure to return the camera to its original
position as shown in the right figure. If it is in
any other position when it is put away, the
camera head or the lens may be damaged.
(3) Turn the lighting unit to the position shown in the right
figure.
Note: Be sure to return the lighting unit to its original
position as shown in the right figure. If it is in
any other position when it is put away, the
lighting unit may be damaged.
(2) Close the lighting unit and the lighting arm unit.
(1) Turn OFF the power switch, and unplug the power
cord and the video cable.
(5) Raise up the column once, and then fall it.
Note: The right storage position of the column is
shown in the right figure. Never apply
excessive force to the column.
Note: Do not hold the head arm unit when carrying
the Presenter.
6. STORING THE VISUAL PRESENTER
