DATA COLLECTION WITH FORMULA™ SOFTWARE APPLICATIONS
2 DATA COLLECTION WITH FORMULA™ APPLICATIONS
2.1 QUICK START
The Formula™ comes with an application named PALPRO loaded in memory.
PALPRO includes two useful data-collection programs for using the Formula™
without additional programming. Follow the steps below to begin using the Formula™
with PALPRO immediately. Page references show where to find more information.
1. Turn the Formula™ on by pressing the <PWR> key. The following screen
appears:
Select
Font
F1 = Wide English
F2 = Normal English
F3 = Simplified Chinese
F4 = Traditional Chinese
2. Select the font. The following screen appears:
FORMULA
Ver.: 1.00
System
RAM 1MB
01/01/08
00:21:48
Press F-key
NOTE
If the Formula™ does not turn on when the <PWR> key is pressed,
you many need to recharge the main battery.
3. Press any function key to move to the next screen:
APPLICATION/TEST
F1=PALPRO
F2=SIMPLEAPPL
4. Once the unit has been initialized, the display will show the APPLICATION
menu in the Figure above.
