18
OPERATION
FEATURES
1. Throttle Control – Used to control
Engine Speed
2. Hour Meter – Indicates hours of
operation
3. Choke Control – Used when starting a
cold engine
4. PTO Switch – Used to engage or
disengage the deck blades
5. Ignition Switch – Used to start or stop
the engine
6. Deck Lift Handle – Used to raise and
lower the cutting deck
7. Control Levers / Parking Brake – Sets the
speed of the mower in both the forward and
reverse directions and also turns the mower /
Engages and disengages the Automatic
Parking Brake system
8. Hydro Bypass – Engages transmissions for
normal operation and disengages
transmissions for pushing or pulling the unit
9. Fuel Tanks – Dual 2.0 gal fuel tanks
10. Seat Slide
11. Battery
12. Pivoting Front Axle
13. Discharge Chute
Left Control Panel Right Control Panel
Rear of Unit
1 2
3
4
5
6
8
11
