55
Section 8
1 04019-04 Nut, Serr. Flange 3/8-16
2 48807 Spring
3 04001-08 Bolt, Hex Head 5/16-18 x 3/4”
4 04001-163 Bolt, Hex Head 1/2-13 x 3-3/4”
5 04001-52 Bolt, Hex Head 1/2-13 x 2-1/2”
6 04021-19 Nut, 1/2-13 Center Lock
7 483190 Wheel Motor, Hydro-Gear
8 04063-25 Key, Woodruff 5/16 x 1”
9 461438 Wheel Hub Assembly
10 481601 Brake Band Assembly
11 482061 Bushing, Self Align
12 48680 Nut, Hex Castle 1.0-20 UNEF
13 04061-06 Cotter Pin, 9/64 x 1-1/2”
14 04028-02 Lug Nut, 1/2-20
15 482044 (48”) Wheel Assembly 23 x 9.5 -12
481659 (48”) Rim
482413 (52”) Wheel Assembly 23 x 9.5 -12
482414 (52”) Rim
482194 (48” & 52”) Tire 23 x 9.5 - 12
16 04004-46 Brake Rod Stud, 3/8-24 x 8.125
17 04020-14 Nut, 3/8-24 UNF
18 423279 Plate Weldment, Motor Backing
19 04064-16 Clevis Pin, 3/8 x 1.93”
20 04069-01 Pin, Rue Cotter 3/8 Dia.
21 461471 Brake Linkage LH
461472 Brake Linkage RH
22 48114-04 Grease Fitting, 1/4-28
23 04020-25 Nut, 3/8-24 UNF
24 04050-01 Retaining Ring, .625 Ext.
25 04021-10 Nut, Elastic Stop 5/16-18
26 04041-07 Flatwasher, 3/8-.391 x .938 x .105
27 04001-31 Bolt, Hex Head 3/8-16 x 2-1/2”
28 04001-166 Bolt, Hex Head 3/8-24 x 3-3/4”
29 04061-02 Cotter Pin, 3/32 x 3/4”
30 04001-20 Bolt, Hex Head 3/8-16 x 1-1/2”
31 451463 Brake Shaft
32 04021-09 Nut, Elastic Stop 3/8-16
33 48544 Rod End, 3/8-24 LH Thread
34 04064-02 Clevis Pin, 3/8 x 1.06
35 48343-04 Clevis, 3/8-24
36 482102 Grip, Brake Lever
37 04019-04 Nut, Serr. Flange 3/8-16
38 461509 Brake Lever (includes item 36)
39 04001-22 Bolt, Hex Head 3/8-16 x 2-3/4”
40 04020-17 Nut, 3/8-24 UNF-2B LH Thread
41 422483 Lever, Brake
42 45974 Shaft Weldment, Pivot
43 43495 Pin, Pivot
44 04008-01 Bolt, Serr. Flange 1/2-20 x 4.563”
Ref. Part
No. No. Description
BRAKE COMPONENTS
* Common hardware which should be purchased locally. All bolts Grade 5 plated, all other fasteners zinc plated.
