47
Section 8
STC FIXED ROLL-OVER PROTECTION SYSTEM
1 9506 STC Fixed ROPS Accessory (incl. all items listed)
2 04001-145 Bolt, Hex Head 1/2-13 x 3-1/2”
3 04021-19 Nut, Center Lock 1/2-13
4 483412 Retractable Seat Belt
5 04040-13 Flatwasher, 1/2-.562 x 1.375 x .109
6 461990 Seat Hardware Kit, STC
7 483451 Bracket
Ref. Part
No. No. Description
