Patriot Products 1900 Chainsaw User Manual



12
S
DO NOT cut down a partially fallen tree
with your saw. Be extremely cautious with
partially fallen trees that may be poorly
supported. When a tree doesn’t fall com-
pletely, set the sawaside and pull down the
tree with a cable winch, block and tackle,
or tractor.
CUTTING A FALLEN TREE
(BUCKING)
Bucking is the term used for cutting a fallen
tree to the desired log size.
WARNING:
Do not stand on the log
being cut. Any portion can roll causing loss
of footing and control. Do not stand downhill
of the log being cut.
IMPORTANT POINTS
S
Cut only one log at a time.
S
Cut shattered wood very carefully; sharp
pieces of wood could be flung toward oper-
ator.
S
Use a sawhorse to cut small logs. Never
allow another person to hold t he log while
cutting and never hold the log with your leg
or foot.
S
Do not cut in a n area where logs, limbs,
and roots are tangled such as in a blown
down area. Drag the logs into a clear area
before cutting by pulling out exposed and
cleared logs first.
TYPES OF CUTTING USED FOR
BUCKING
WARNING:
If saw becomes
pinched or hung in a log, don’t try to force it
out. You can lose control of the sawresulting
in injury and/or damage to the saw. Stop t he
saw, drive awedge of plastic orwood into the
cut until the saw can be removed easily. Re-
start the sawand carefully reenter the cut. To
avoid kickback and chain damage, do not
use ametal wedge. Do not attempt to restart
your saw when it is pinched or hung in a log.
Use a wedge to remove pinched saw
Turn saw OFF and us e a plastic or
wooden wedge to force cut open.
Overcutting begins on the top side of thelog
with the bottom of the saw against the log.
When overcutting use l ight downward pres-
sure.
Overcutting
Undercutting
Undercutting involves cutting on the under-
side of the log with top of saw against thelog.
When undercutting use light upward pres-
sure. Hold saw firmly and maintain control.
The saw will tend to pus h back toward you.
WARNING:
Never turn saw upside
down to undercut. The saw cannot be con-
trolled in this position.
Always make your first cut on the compres-
sion side of the log. The compression sideof
the log is where the pressure of the log’s
weight is concentrated.
Second cut
First cut on compression side of log
First cut on compression side of log
Second cut
BUCKING WITHOUT A SUPPORT
S
Overcut through
1/3
of the diameter of the
log.
S
Roll the log over and finish with a second
overcut.
S
Watch f or logs with a compression side to
prevent the saw from pinching. See il-
lustrations for cutting logs with a compres-
sion side.
BUCKING USING A LOG OR
SUPPORT STAND
S
Remember your first cut is always on the
compression side of the log.
(Refer to the illustrations below for your
first and second cut)
S
Your first cut should extend
1/3
of the
diameter of the log.
S
Finish with your se cond cut.
1
st
Cut
2
nd
Cut
Usingalogforsupport
2
nd
Cut
1
st
Cut
