Machine Component Identification - Item #165938N
8
Figure 1 (Ref. 1-12)
Ref. Description Ref. Description
1 Gas Cap with Gauge 11 Super Silent Muffler
2 6.5 Gallon Gas Tank 12 Air Cleaner
3 Battery Box 13 Engine Key Switch
4 Circuit Breakers 14 Fuel Valve
5 120V 15A Duplex Receptacle 15 Choke Lever
6 Fuel Selector Switch 16 Recoil
7 120V 20A Duplex Receptacle 17 LPG / NG - 3/4” NPT Inlet
8 120/240V 30A Locking Receptacle 18 Demand Regulator
9 Vibration Isolation Mounts 19 Generator Head
10 Oil Drain Plug
Figure 2 (Ref. 13-19)
