DCA800SSK2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (09/03/09) — PAGE 107
NAMEPLATE AND DECALS ASSY.
NO. PART NO. PART NAME QTY. REMARKS
12 B9521100404 DECAL : SAFETY INSTRUCTIOS ......................................1 ........... B92110040
13 B1552000103 DECAL : CAUTION ..............................................................2 ........... B15200010
CONTROL PANEL & BOX GROUP
21 0800520100 PLATE : ON OFF ................................................................1 ........... AT 202
22 0800520904 PLATE : AMMETER CHANGE OVER SWITCH ..................1 ........... N2438
23 0800520814 PLATE : VOLTMETER CHANGE OVER SWITCH ...............1 ........... N2439
24 0800564004 PLATE : OFF .......................................................................2 ........... N3805
25 0800565004 PLATE : ON .........................................................................2 ........... N3806
26 0840624504 DECAL : CIRCUIT BREAKER .............................................1 ........... S3031
27 0840624604 DECAL : PANEL LIGHT SWITCH .......................................1 ........... S3032
28 0840624704 DECAL : PILOT LAMP .........................................................1 ........... S3033
29 0840624804 DECAL : VOLTAGE REGULATOR .......................................1 ........... S3034
210 B9531100604 DECAL : WARNING ELECTRIC SHOCK HAZARD ............2 ........... B93110060
211 C5551000303 DECAL : SETTING FOR OUTPUT VOLTAGE .....................1 ........... C55100030
212 C5561101003 DECAL : WHISPERWATT 800 ............................................1 ........... C56110010
ENGINE & RADIATOR GROUP
31 0800689204 DECAL : COOLING WATER ................................................1 ........... S961
32 B9504000304 DECAL : CAUTION HOT PARTS .........................................1 ........... B90400030
33 B9504000404 DECAL : WARNING MOVING PARTS .................................2 ........... B90400040
34 B9504100104 DECAL : WARNING HOT COOLANT ..................................1 ........... B90410010
35 0600501100 DECAL : WARNING.............................................................1 ........... 0600501100
36 0966810000 DECAL : FUEL PRIMING 1
ENGINE OPERATING PANEL GROUP
51 C5551001203 DECAL : OPERATING PANEL ............................................1 ........... C55100120
51A 0840647804 DECAL : EMERGENCY STOP ............................................1 ........... S4100
52 C5551001104 DECAL : WARNING LAMP ..................................................1 ........... C55100110A
53 C0551000504 DECAL : BATTERY SWITCH ..............................................1 ........... C05100050
OUTPUT TERMINAL GROUP
61 0840614104 DECAL : GROUND ..............................................................1 ........... S2635
62 9039209064 DECAL : START CONTACT ................................................1 ........... S4468
63 0840655704 DECAL : TERMINAL COVER STOPPER ............................1 ........... S4516
64 B9511100304 DECAL : WARNING.............................................................1 ........... B91110030
65 B9511100404 DECAL : WARNING ELECTRIC SHOCK HAZARD ............1 ........... B93110050
66 B9531100504 DECAL : WARNING ELECTRIC SHOCK HAZARD ............1 ........... B93110050
67 C0551000404 DECAL : 3 PHASE OUTPUT TERMINAL ............................1 ........... C05100040
68 C5551000403 DECAL : RECEPTACLE & CIRCUIT BREAKER .................1 ........... C55100040
69 0840619904 DECAL : DANGER HIGH VOLTAGE ....................................1 ........... S2731
