DCA10SPX4/DCA10SPXU4 — OPERATION AND PARTS MANUAL — REV. #0 (08/05/09) — PAGE 69
1
DCA10SPX4/DCA10SPXU4 — ENCLOSURE ASSY.
ENCLOSURE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
25 B0464001002 ROOF PANEL ................................................... 1 ........... DCA10SPX4
25 M0464000102 ROOF PANEL ................................................... 1 ........... DCA10SPXU4
25A B0494500104 ACOUSTIC SHEET .......................................... 1 ........... DCA10SPX4
25A M0494500604 ACOUSTIC SHEET .......................................... 1 ........... DCA10SPXU4
26 0016908020 HEX HEAD BOLT 16
27 8452023004 COVER ............................................................. 1 ........... DCA10SPX4
27 M1465400104 COVER ............................................................. 1 ........... DCA10SPXU4
28 0016908020 HEX HEAD BOLT 2
29 B0454100503 SIDE PANEL ..................................................... 1 ........... DCA10SPX4
29 M0454100103 SIDE PANEL ..................................................... 1 ........... DCA10SPXU4
29A B0494400414 LINING 1
30 0016908035 HEX HEAD BOLT 6
31 B0455300424 DUCT 1
31A B0495401014 LINING 1
32 0207006000 HEX NUT 6
33 B0454000903 SIDE DOOR...................................................... 1 ........... DCA10SPX4
33 M0454000203 SIDE DOOR...................................................... 1 ........... DCA10SPXU4
33A B0494400504 ACOUSTIC SHEET .......................................... 1 ........... DCA10SPX4
33A M0494401204 ACOUSTIC SHEET .......................................... 1 ........... DCA10SPXU4
34 B0454000803 SIDE DOOR...................................................... 1 ........... DCA10SPX4
34 M0454000303 SIDE DOOR...................................................... 1 ........... DCA10SPXU4
34A B0494400604 ACOUSTIC SHEET .......................................... 1 ........... DCA10SPX4
34A M0494401704 ACOUSTIC SHEET .......................................... 1 ........... DCA10SPXU4
35 B0454300404 DUCT 1
36 0207006000 HEX NUT 5
37 B9114000002 DOOR HANDLE 1
38 0021806015 MACHINE SCREW 4
39 0845047204 HINGE 2
39A 0845045004 WASHER 2
40 0845047104 HINGE 2
40A 0845045004 WASHER 2
41 0016908020 HEX HEAD BOLT 8
42 0845031504 CAP 4
44 B1262800004 PLATE 1
45 0016906015 HEX HEAD BOLT 4
46 0019208020 HEX HEAD BOLT 1
47 B0444600104 WINDOW PLATE 1
48 0027103010 MACHINE SCREW 4
48A 0207003000 HEX NUT 4
49 0600500090 EMBLEM 1
50 0021106015 MACHINE SCREW 2
51 B1454301004 DUCT 1
52 0207006000 HEX NUT 4
