DCA10SPX4/DCA10SPXU4 — OPERATION AND PARTS MANUAL — REV. #0 (08/05/09) — PAGE 49
1
DCA10SPX4/DCA10SPXU4 — CONTROL PANEL ASSY.
CONTROL PANEL ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 B0224005103 CONTROL PANEL ........................................... 1 ........... DCA10SPX4
1 M0224000003 CONTROL PANEL ........................................... 1 ........... DCA10SPXU4
2 0601800455 FREQUENCY METER, 45~65 Hz 1
3 0601805745 AC AMMETER, O~75/5A 1
4 0601800281 AC VOLTMETER, O~150/300V 1
5 0601840073 RHEOSTAT (VR), 2W 1K OHM 1
6 0601840121 KNOB, RHEOSTAT 1
7 0601808803 CIRCUIT BREAKER, 1P 20A 1
8 0601808807 CIRCUIT BREAKER, 1P 30A 1
9 0601808808 CIRCUIT BREAKER, 2P 30A 1
10 0601808809 CIRCUIT BREAKER, 2P 45A 1
11 B0262600804 BRACKET 1
11-1 0222100115 RUBBER CUSHION 1
12 0021806015 MACHINE SCREW 2
13 1628663602 STARTER SWITCH.......................................... 1 ........... REPLACES P/N 3741059113
13A 3741055150 KEY, STARTER SWITCH
14 0601810523 WARNING LAMP UNIT 1
14A 0601810830 BULB 4
15 0601800682 HOUR METER 1
15A 0027403010 MACHINE SCREW 2
15B 0207003000 HEX NUT 2
16 0605010060 HINGE 2
17 0027103008 MACHINE SCREW 8
18 0021806030 MACHINE SCREW 2
19 0601808817 CIRCUIT BREAKER, 45A 1
20 0021005080 MACHINE SCREW 4
21 0601801123 CURRENT TRANS., AMMETER, 150/5A 1
22 0027105015 MACHINE SCREW 2
23 0601842304 RESISTOR, GG20W50 OHM 1
24 0027104010 MACHINE SCREW 2
25 0601820038 RECTIFIER 1
26 0027104020 MACHINE SCREW 1
27 0601820663 AUTOMATIC VOLTAGE REGULATOR 1
28 0027105015 MACHINE SCREW 4
29 0601815759 TERMINAL BOARD 1
30 0027104020 MACHINE SCREW 2
31 1G38560601 ENGINE CONTROL UNIT ............................... 1 ........... REPLACES P/N 0602202634
32 0021005050 MACHINE SCREW 2
32A 0040005000 WASHER, LOCK 2
32B 0041205000 WASHER, FLAT 2
33 B0214600404 FUSE BOX 1
33A 0601806642 FUSE, 5A 5
33B 0601806645 FUSE, 10A 4
33C B0551002104 DECAL : FUSE BOX 1
34 0027105015 MACHINE SCREW 2
35 RP42153731 RELAY ASSY ................................................... 1 ........... REPLACES P/N 0602202635
36 6888153542 RELAY ............................................................. 1 ........... REPLACES P/N 0602202566
