SECTION 3: HARDWARE PACK
Please identify each piece of the hardware pack as
shown in Figure 1.
Figure 1
SECTION 4: UNPACKING
Removing Unit From Carton
• Remove staples, break glue on top flaps, or cut
tape at carton end and peel along top flap to open
carton.
• Remove loose parts included with unit (i.e.,
operator’s manual, oil, etc.).
• Cut corners and lay carton down flat. Remove
packing material.
• Roll or slide unit out of carton. Check carton
thoroughly for loose parts.
NOTE: Make sure not to crimp the cables while
removing the loose parts or the entire unit from the
carton.
NOTE: Reference to right or left hand side of the mower
and/or front or behind the mower is observed from the
operating position.
SECTION 5: ASSEMBLING YOUR LAWN MOWER
Tools Required
• Pair of Pliers
• Funnel
• Set of adjustable wrenches
Disconnecting Spark Plug
• Before setting up your lawn mower, disconnect the
spark plug wire from the spark plug, and ground it
against the engine. See Figure 2.
• Attach the spark plug wire to a bolt on the engine to
ground it.
Figure 2
Assembling Handle
• Remove grass bag from the unit and set it out of the
way. See Figure 3 (step 1).
• Remove any packing material which may be
between the upper and lower handles for shipping
purposes.
Figure 3
• Raise the lower handle in the direction shown in
Figure 3 (step 2) till it snaps into place.
Wing Nut 1/4-20 (2) Carriage Bolt 1/4-20 (2)
Spark Plug
Wire
Spark Plug
1. Move bag
2. Lift lower handle
3. Lift upper
handle
away
