Section 6 Specifications and Capacities
7/14/08
RC45180 & RCM45180 Rotary Cutter 312-382M
Land Pride
Table of Contents
Section 6 Specifications and Capacities
RC45180 & RCM45180 Rotary Cutter
Cutting Width
Overall Width
Minimum Transport Width
180”
190”
96”
Cutting Height 2” - 14”
Overall Length 204”
Deck Material Thickness 10 gauge
Deck Height 10”
Hitch Type Pull Self - Leveling
Blades - 6 (2 per Carrier) 1/2” x 4” Heat Alloy Steal
Free Swinging
High Lift
Low Friction
Blade Tip Speed 540 RPM PTO: FPM RPM
Center Blade 14,853 788
Wing Blade 14,112 907
1000 RPM PTO:
Center Blade 15,569 826
Wing Blade 14,486 930
Blade Holders Center: 3/16” x 27” Oval Pan
Wing: 3/16” x 15” Round Pan
PTO Drive Shafts 540 PTO: ASAE Category 5 {Input Shafts}
ASAE Category 4 {Output Shafts}
1,000 PTO: ASAE Category 4 {Input / Output}
Driveline Slippage Protection Dual plate Bellevile type slip clutches on each blade gearbox
Power Divider 540 RPM: PTO Driven 1:1.15 Speed-Up
Tapered Roller Bearings, Beveled Gears
Cast Iron Housing, 125 Horse Power
1000 RPM: PTO Driven 1.3:1 Reduction
Tapered Roller Bearings, Beveled Gears
Cast Iron Housing, 180 Horse Power
Gear Boxes 540 RPM: PTO Driven 1:1.46 Speed-Up
Tapered Roller Bearings, Beveled Gears
Cast Iron Housing, 75 Horse Power
1000 RPM: {wings} PTO Driven 1:1.21 Speed-Up;
{center} 1.21:1 Reduction
Tapered Roller Bearings, Beveled Gears
Cast Iron Housing, 75 Horse Power
Tailwheel - Pull Type 6.00 x 9 x 21 Laminated or
5 x 15 Rim only or 21” Solid Core or
25.5 x 8.0-14 18 Ply-tube-type
Shock Load Suspension Four Compression type springs on center wheels
Four Rubber Bumper cushions on wing wheels
Machine Weight (With front / rear chain guards) 4,400 lbs.
Tongue Weight 1,600 lbs.
Recommended PTO Horse Power 50 - 150
