Model CG22EAS (SL) CG22EAS (S) CG22EAD (SL) CG22EAB (L)
Engine Size (ml) 21.1
Spark Plug NGK BMR7A or equivalent
Fuel Tank Capacity (l) 0.45
Dry Weight (kg) 4.4 4.7 4.7 3.9
Sound pressure level
LpA (dB (A))
(EN27917)
Equivalent
90 89 91 90 90
Measured sound
power level LwA
(dB (A))
(ISO10884)
Equivalent
104 104 103 104 104
Measured sound
power level LwA
(dB (A))
(2000/14/EC)
Racing
107 107 106 107 107
Guaranteed sound
power level LwA
(dB (A))
(2000/14/EC)
Racing
108 109 108 108 109
Vibration level (m/s
2
)
(ISO7916)
Equivalent (Front / Left handle)
Equivalent (Rear / Right handle)
Idling (Front / Left handle)
Idling (Rear / Right handle)
Racing (Front / Left handle)
Racing (Rear / Right handle)
6.7
4.1
4.9
3.3
8.0
4.7
4.5
4.8
2.7
3.4
5.8
5.9
4.7
4.3
2.7
3.4
6.1
5.1
7.7
4.7
4.1
3.7
10.1
5.5
5.5
6.6
5.5
4.7
5.5
8.1
NOTE
Equivalent noise level/vibration level are calculated as the time-weighted energy total for noise/vibration levels under various working
conditions with the following time distribution: 1/2 Idle, 1/2 racing.
* All data subject to change without notice.
ASSEMBLY PROCEDURES
Drive shaft to engine (Fig. 1)
Loosen tube locking bolt (1) about ten turns so that the bolt point will
not obstruct drive shaft tube to be inserted. When inserting drive
shaft tube, hold the tube locking bolt outward preventing inside
fi tting from obstructing as well.
Insert the drive shaft into the clutch case of the engine properly until
the marked position (2) on the drive shaft tube meets the clutch
case.
Some models may come with the drive shaft already installed.
1
2
1
2
Fig. 1
SPECIFICATIONS
